ISA Isabella 13 A LX [15/42] Maintenance
![ISA Isabella 10 A LX [15/42] Maintenance](/views2/1323206/page15/bgf.png)
15
EN
ISABELLA LX
USE AND MAINTENANCE MANUAL ICE CREAM CABINETS
428000085
237
9. MAINTENANCE
The Staff in charge of the appliance must control and respect the expiry dates for maintenance,
given in the table below, calling the authorised Technical After-sales assistance when indicated.
OPERATION FREQUENCY
ORDINARY
EXTRAORDINARY
AUTHORISED
PERSONNEL
Depending on the
Use and Necessity
Monthly
six-month
Annual
CLEANING THE EXTERNAL SURFACES
XX
USER
CLEANING THE ACCESSIBLE INTERNAL PARTS
(without the use of tools)
XX
CONTROL POWER SUPPLY CABLE,
PLUGS AND / OR ELECTRICAL SOCKETS
XX
INTEGRITY CONTROL SEAL
XX
FILTER CLEANING CONDENSING UNIT
(whenever present)
XX
CLEANING THE DEFROSTING WATER COLLECTION TRAY
XX
TECHNICAL
ASSISTANCE
SERVICE
CONDENSER CLEANING
XXX
CHECK COMPRESSORE OIL LEVEL
(whenever present)
XX
AIR TANK DRAINING
(whenever present)
XX
CONTROL PNEUMATIC CONNECTIONS
(whenever present)
XX
INTEGRITY CONTROL PIPE COOLING SYSTEM
XX
INSPECTION OF CABLES
INTERNAL CONNECTIONS AND POWER
XX
CLEANING CONDENSATE DRYING SPONGES
(whenever present)
XX
LAMP / LED REPLACEMENT
(whenever present)
X
CONTROL PANEL REPLACING
(electronic control unit - thermostat - etc)
X
REPLACEMENT POWER SUPPLY CABLE, PLUGS AND / OR ELECTRICAL SOCKETS
X
Attention
After all maintenance it is mandatory to perform all electric safety tests in agreement with the IEC
EN 50106 Standard.
