ISABELLA LX
USE AND MAINTENANCE MANUAL ICE CREAM CABINETS
428000085
237
1 Symbols of Compliance
2 Manufacturer's address
3 Production Order
4 Type
5 Model Name
6 Article
7 Serial Number
8 Production Date
9 - 10 Power supply Voltage and Frequency
11 Gross Capacity
12 Absorption at Rated Capacity
13 Absorption during Defrosting
14 Absorption of Heating Elements
15 Lamp Power
16 Fuse Value
17 Climate Class
18 Number of Motors
19 Type of Coolant
20 Amount of Coolant
21 Safety Class
22 - 23 Customer order
24 RAEE Mark
3. EQUIPMENT IDENTIFICATION
• Find the label affi xed on the machine to read the technical data.
• Check the machine model and the power supply voltage before you
perform any operation.
• If you uncover mismatches, contact the manufacturer or the company
that supplied the machine immediately.
