ISABELLA LX

USE AND MAINTENANCE MANUAL

428000085

237

ICE CREAM CABINETS

Attention

The electronic control board is installed

already programmed.

Any changes to the control board settings

can be carried out exclusively by qualiﬁ

ed technical personnel.

KEYS - SINGLE PRESS

Not applicable.

SBR

To start a manual defrosting cycle, press for at least 2 seconds.

To display or modify the set-point.

Press and release the key to display the temperature.

To go back to viewing the temperature set, wait 5 seconds or press the key again

In programming mode, selects a parameter or conﬁ rms a value.

In programming mode, scrolls the codes of the parameters or increases its value.

Activates the Continuous Cycle function when present.

MAXIMUM TEMPERATURE DISPLAY

Press and release the key (the “Hi” message will be displayed followed by the maximum

temperature reached).

Press the key or wait 5 seconds to go back to displaying normal temperature.

DOWN

In programming mode, scrolls the codes of the parameters or decreases its value.

Activates the High and Low Humidity function when present.

MINIMUM TEMPERATURE DISPLAY

Press and release the key (the “Lo” message will be displayed followed by the minimum

temperature reached).

Press the key or wait 5 seconds to go back to displaying normal temperature.

Switches the instrument on or off.

Pressed for at least 2 seconds, it displays “OFF”

In this conﬁ guration the loads and all adjustments are disabled; to take the instrument

back to ON press again for at least 2 seconds.

12.2 USER INTERFACE - XR44CX
