Mitsubishi Electric SEZ-KD35VAQ / SUZ-KA35VA [10/34] Error codes indication

7. Other Functions

ON/OFF

ERROR CODE

If you have entered contact number to be called in the event of a prob-

lem, the screen displays this number. (You can set this up under Func-

tion Selection of remote controller. For information, refer to section 8.)

Indoor Unit’s

Refrigerant

Address

Error Code

Indoor Unit No.

Alternating

Display

ON/OFF

˚C

ERROR CODE

ON/OFF

CALL:XXXX

XXX:XXX

Error Code

When the Check button is pressed:

ON lamp

(Flashing)

7.2.3. Error Codes indication

● If the ON lamp and error code are both flashing: This means that the air

conditioner is out of order and operation has been stopped (and cannot

resume). Take note of the indicated unit number and error code, then

switch off the power to the air conditioner and call your dealer or servicer.

● If only the error code is flashing (while the ON lamp remains lit): Opera-

tion is continuing, but there may be a problem with the system. In this

case, you should note down the error code and then call your dealer or

servicer for advice.

* If you have entered contact number to be called in the event of a

problem, push the Check button to display it on the screen. (You can

set this up under Function Selection of remote controller. For infor-

mation, refer to section 8.)

8. Function Selection

Function selection of remote controller

The setting of the following remote controller functions can be changed using the remote controller function selection mode. Change the setting when

needed.

Item 1

1. Change Language

(“CHANGE

LANGUAGE”)

2. Function limit

(“FUNCTION

SELECTION”)

3. Mode selection

(“MODE SELEC-

TION”)

4. Display change

(“DISP MODE

SETTING”)

Item 2

Language setting to display

(1) Operation function limit setting (operation lock) (“LOCKING

FUNCTION”)

(2) Use of automatic mode setting (“SELECT AUTO MODE”)

(3) Temperature range limit setting (“LIMIT TEMP FUNCTION”)

(4) Use of automatic filter elevation panel up/down operation

mode setting

(5) Use of fixed airflow direction mode setting

(1) Remote controller main/sub setting (“CONTROLLER MAIN/

SUB”)

(2) Use of clock setting (“CLOCK”)

(3) Timer function setting (“WEEKLY TIMER”)

(4) Contact number setting for error situation (“CALL.”)

(1) Temperature display °C/°F setting (“TEMP MODE °C/°F”)

(2) Suction air temperature display setting (“ROOM TEMP DISP

SELECT”)

(3) Automatic cooling/heating display setting (“AUTO MODE

DISP C/H”)

Item 3 (Setting content)

• Display in multiple languages is possible

• Setting the range of operation limit (operation lock)

• Setting the use or non-use of “automatic” operation mode

• Setting the temperature adjustable range (maximum, minimum)

(For this model, this function is not available.)

• Selecting main or sub remote controller

* When two remote controllers are connected to one group, one controller

must be set to sub.

• Setting the use or non-use of clock function

• Setting the timer type

• Contact number display in case of error

• Setting the telephone number

• Setting the temperature unit (°C or °F) to display

• Setting the use or non-use of the display of indoor (suction) air tempera-

ture

• Setting the use or non-use of the display of “Cooling” or “Heating” display

during operation with automatic mode
