Contents

1. Safety Precautions

2. Parts Names

 PKA-RP·KAL

Filter

Air inlet

Air outlet

Louver

Vane

 Before installing the unit, make sure you read all the

“Safety Precautions”.

 The “Safety Precautions” provide very important

points regarding safety. Make sure you follow them.

 Please report to or take consent by the supply

authority before connection to the system.

Disposing of the unit

When you need to dispose of the unit, consult your dealer.

Caution:

• Do not use any sharp object to push the buttons, as this may

damage the remote controller.

• Never block or cover the indoor or outdoor unit’s air inlets or

outlets.

• When you notice exceptionally abnormal noise or vibration, stop

operation, turn off the power switch, and contact your dealer.

• Never insert fingers, sticks etc. into the air inlets or outlets.

• If you detect odd smells, stop using the unit, turn off the power

switch and consult your dealer. Otherwise, a breakdown, electric

shock or fire may result.

• This air conditioner is NOT intended for use by children or infirm

persons without supervision.

• Young children must be supervised to ensure that they do not

play with the air conditioner.

• If the refrigeration gas blows out or leaks, stop the operation of

the air conditioner, thoroughly ventilate the room, and contact

your dealer.

Warning:

• For appliances not accessible to the general public.

• The unit must not be installed by the user. Ask the dealer or an

authorized company to install the unit. If the unit is installed

improperly, water leakage, electric shock or fire may result.

• Do not stand on, or place any items on the unit.

• Do not splash water over the unit and do not touch the unit with

wet hands. An electric shock may result.

• Do not spray combustible gas close to the unit. Fire may result.

• Do not place a gas heater or any other open-flame appliance

where it will be exposed to the air discharged from the unit.

Incomplete combustion may result.

• Do not remove the front panel or the fan guard from the outdoor

unit when it is running.

Symbols used in the text

Warning:

Describes precautions that should be observed to prevent danger

of injury or death to the user.

Caution:

Describes precautions that should be observed to prevent damage

to the unit.

Symbols used in the illustrations

: Indicates a part which must be grounded.

 Indoor Unit

PKA-RP·KAL

Fan speed 3 speeds (with auto)

Vane Auto swing

Louver Manual

Filter Normal

Filter cleaning indication 100 hr

1. Safety Precautions ................................................................2

2. Parts Names ..........................................................................2

3. Screen Configuration .............................................................5

4. Setting the Day of the Week and Time ..................................5

5. Operation ...............................................................................5

6. Timer .....................................................................................8

7. Other Functions ...................................................................11

8. Function Selection ...............................................................12

9. Emergency Operation for Wireless Remote-controller ........16

10. Care and Cleaning ..............................................................16

11. Troubleshooting ...................................................................17

12. Specifications ......................................................................18

Front grille

Emergency operation switch

Note

This symbol mark is for EU countries only.

This symbol mark is according to the directive 2002/96/EC Article 10 Information for users and Annex IV, and/or to the

directive 2006/66/EC Article 20 Information for end-users and Annex II.

Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and components which can be

recycled and/or reused. This symbol means that electrical and electronic equipment, batteries and accumulators, at their end-of-

life, should be disposed of separately from your household waste. If a chemical symbol is printed beneath the symbol (Fig. 1), this

chemical symbol means that the battery or accumulator contains a heavy metal at a certain concentration.

This will be indicated as follows: Hg: mercury (0,0005%), Cd: cadmium (0,002%), Pb: lead (0,004%)

In the European Union there are separate collection systems for used electrical and electronic products, batteries and accumulators.

Please, dispose of this equipment, batteries and accumulators correctly at your local community waste collection/recycling centre.

Please, help us to conserve the environment we live in!

Fig. 1
