Liebherr ICBS 3314 [11/13] Malfunction
![Liebherr ICBS 3314 [11/13] Malfunction](/views2/1331285/page11/bgb.png)
u
Read the appliance
designation
Fig. 9 (1)
, service
No.
Fig. 9 (2)
and
serial No.
Fig. 9 (3)
off the type plate
located inside the
appliance on the left-
hand side.
Fig. 9
u
Notify the customer service, specifying the fault, appliance
designation
Fig. 9 (1)
, service No.
Fig. 9 (2)
and serial No.
Fig. 9 (3)
.
w
This will help us to provide you with a faster and more accu-
rate service.
u
Keep the appliance closed until the customer service
arrives.
w
The food will stay cool longer.
u
Pull out the mains plug (not by pulling the connecting cable)
or switch off the fuse.
7 Malfunction
Your appliance is designed and manufactured for a long life
span and reliable operation. If a malfunction nonetheless
occurs during operation, check whether it is due to a handling
error. In this case you will have to be charged for the costs
incurred, even during the warranty period. You may be able to
rectify the following faults yourself:
Appliance does not work.
→
The appliance is not switched on.
u
Switch on the appliance.
→
The power plug is not properly inserted in the wall socket.
u
Check power plug.
→
The fuse of the wall socket is not in order.
u
Check fuse.
The compressor runs for a long time.
→
The compressor switches to a low speed when little cold is
needed. Although the running time is increased as a result,
energy is saved.
u
This is normal in energy-saving models.
→
SuperFrost is activated.
u
The compressor runs for longer in order to rapidly cool the
food. This is normal.
→
SuperCool is activated.
u
The compressor runs for longer in order to rapidly cool the
food. This is normal.
A LED on the bottom rear of the appliance (at the
compressor) flashes repeatedly every 5 seconds*.
→
There is a fault.
u
Please contact the after-sales service (see Maintenance).
Excessive noise.
→
Due to the various speed steps, speed-regulated*
compressors can generate different running noises.
u
The sound is normal.
A bubbling and gurgling noise.
→
This noise comes from the refrigerant flowing in the refriger-
ation circuit.
u
The sound is normal.
A quiet clicking noise.
→
The noise is produced whenever the refrigeration unit
(motor) automatically switches on or off.
u
The sound is normal.
A hum. It is briefly a little louder when the refrigeration
unit (the motor) switches on.
→
The refrigeration increases automatically when the Super-
Frost, function is activated, fresh food has just been placed
in the appliance or the door has been left open for a while.
u
The sound is normal.
→
The refrigeration increases automatically when the Super-
Cool function is activated, fresh food has just been placed
in the appliance or the door has been left open for a while.
u
The sound is normal.
→
The ambient temperature is too high.
u
Solution: (see 1.2)
A low hum.
→
The sound is produced by air flow noise of the fan.
u
The sound is normal.
Vibratory noise.
→
The appliance is not fixed to the ground. The running of the
cooling unit therefore makes objects and adjacent furniture
vibrate.
u
Check installation and reposition appliance as required.
u
Move bottles and containers apart.
The temperature display indicates: F0 to F9
→
There is a fault.
u
Please contact the after-sales service (see Maintenance).
The temperature display indicates power failure . The
warmest temperature reached during the power failure
appears in the temperature display.
→
The freezer temperature rose too high over the last hours or
days due to a power failure or power interruption. When the
power interruption is over, the appliance will continue to
operate in the last temperature setting.
u
To cancel the display of the warmest temperature: press
alarm button
Fig. 2 (11)
.
u
Check the quality of the food. Do not consume spoiled food.
Do not re-freeze thawed food.
DEMO shines in the temperature display.
→
The demo mode is activated.
u
Please contact the after-sales service (see Maintenance).
The outer surfaces of the appliance are warm*.
→
The heat of the refrigeration circuit is used to prevent
condensate from forming.
u
This is normal.
The temperature is not cold enough.
→
The door of the appliance is not properly closed.
u
Close the door of the appliance.
→
Insufficient ventilation.
u
Clear ventilation grilles.
→
The ambient temperature is too high.
u
Solution: (see 1.2) .
→
The appliance was opened too frequently or for too long.
u
Wait to see whether the appliance reaches the required
temperature by itself. If not, please contact the after sales
service (see Maintenance).
→
Too much fresh food was placed inside without SuperFrost.
u
Solution: (see 5.6.5)
→
The temperature is incorrectly set.
u
Set the temperature to a colder setting and check after 24
hours.
→
The appliance is too close to a source of heat (stove, heater
etc).
u
Change the position of the appliance or the source of heat.
→
The appliance was not inserted properly into the recess.
u
Check whether the appliance was inserted correctly and
the door closes properly.
Malfunction
* Depending on model and options 11
