Liebherr ICBS 3314 [4/13] Operating and control elements
![Liebherr ICBS 3314 [4/13] Operating and control elements](/views2/1331285/page4/bg4.png)
-
Please be sure to store alcoholic drinks or
other packaging containing alcohol in tightly
closed containers. Any alcohol that leaks out
may be ignited by electrical components.
Danger of tipping and falling:
-
Do not misuse the plinth, drawers, doors etc.
as a step or for support. This applies particu-
larly to children.
Danger of food poisoning:
-
Do not consume food which has been stored
too long.
Danger of frostbite, numbness and pain:
-
Avoid lasting skin contact with cold surfaces
or refrigerated/frozen food or take protective
steps, e.g. wear gloves. Do not consume ice
cream, water ice or ice cubes immediately
and do not consume them too cold.
Danger of injury and damage:
-
Hot steam can lead to injury. Do not use elec-
trical heating or steam cleaning equipment,
open flames or defrosting sprays to defrost.
-
Do not use sharp implements to remove the
ice.
Please observe the specific information in
the other sections:
DANGER identifies a situation involving direct
danger which, if not obviated, may
result in death or severe bodily
injury.
WARNING identifies a dangerous situation
which, if not obviated, may result in
death or severe bodily injury.
CAUTION identifies a dangerous situation
which, if not obviated, may result in
minor or medium bodily injury.
NOTICE identifies a dangerous situation
which, if not obviated, may result in
damage to property.
Note identifies useful information and tips.
3 Controls and displays
3.1 Operating and control elements
Fig. 2
(1) Refrigerator compart-
ment On/Off button
(9) SuperFrost button
(2) Refrigerator compart-
ment temperature
display
(10) SuperFrost symbol
(3) Refrigerator compart-
ment setting button
(11) Alarm button
(4) SuperCool button (12) Alarm symbol
(5) SuperCool symbol (13) Menu symbol
(6) Refrigerator compart-
ment On/Off button
(14) Child lock symbol
(7) Freezer compartment
temperature display
(15) Power failure symbol
(8) Freezer compartment
setting button
3.2 Temperature display
The following are displayed in normal operation:
-
the warmest freezing temperature
-
the average cooling temperature
The freezer compartment temperature display flashes:
-
the temperature setting is being changed
-
after switch-on the temperature is not yet cold enough
-
the temperature has risen several degrees
Dashes flash in the display:
-
the freezer temperature is above 0 °C.
The following displays indicate malfunction. Possible causes
and corrective action (see Malfunction).
-
F0 to F9
-
The power failure symbol
shines.
4 Putting into operation
4.1 Switching on the appliance
Note
u
The refrigerator compartment is switched on automatically
when the freezer compartment is switched on.
Controls and displays
4 * Depending on model and options
