■ Filter information

Cool

Room

AutoSet temp.

Mode Temp. Fan

Fri

F1 F2 F3 F4

Main

Main display:

Cursor Page

Main menu

Restriction

Energy saving

Night setback

Filter information

Error information

F1 F2 F3 F4

Main menu:

Filter information

Reset

Please clean the filter.

Press Reset button after

filter cleaning.

F1 F2 F3 F4

Filter information

Cancel

Reset filter sign?

Filter sign reset

Main menu:

Navigating through the screens

• To go back to the Main menu ................ [MENU] button

• To return to the previous screen ........... [RETURN] button

6. Care and Cleaning

will appear on the Main display

in the Full mode when it is time to

clean the ﬁlters.

Wash, clean, or replace the ﬁlters

when this sign appears.

Refer to the indoor unit Instruc-

tions Manual for details.

Select "Filter information" from the

Main menu (refer to page 8), and

press the [SELECT] button.

Press the [F4] button to reset ﬁlter

sign.

Refer to the indoor unit Instructions

Manual for how to clean the ﬁlter.

Select "OK" with the [F4] button.

A conﬁrmation screen will appear.

Cool

Room

AutoSet temp.

Mode Temp. Fan

Fri

If two or more indoor units are connected, filter cleaning timing for

each unit may be different, depending on the filter type.

The icon

will appear when the filter on the main unit is due for

cleaning.

When the filter sign is reset, the cumulative operation time of all units

will be reset.

The icon

is scheduled to appear after a certain duration of

operation, based on the premise that the indoor units are installed in a

space with ordinary air quality. Depending on the air quality, the filter

may require more frequent cleaning.

The cumulative time at which filter needs cleaning depends on the

model.

• This indication is not available for wireless remote controller.

Cleaning the filters

• Clean the filters using a vacuum cleaner. If you do not have a vacuum

cleaner, tap the filters against a solid object to knock off dirt and dust.

• If the filters are especially dirty, wash them in lukewarm water. Take

care to rinse off any detergent thoroughly and allow the filters to dry

completely before putting them back into the unit.

Caution:

• Do not dry the filters in direct sunlight or by using a heat source,

such as an electric heater: this may warp them.

• Do not wash the filters in hot water (above 50°C), as this may

warp them.

• Make sure that the air filters are always installed. Operating the

unit without air filters can cause malfunction.

Caution:

• Before you start cleaning, stop operation and turn OFF the power

supply.

• Indoor units are equipped with filters to remove the dust of sucked-

in air. Clean the filters using the methods shown in the following

sketches.

Caution:

• In removing the filter, precautions must be taken to protect your

eyes from dust. Also, if you have to climb up on a stool to do the

job, be careful not to fall.

• When the filter is removed, do not touch the metallic parts inside

the indoor unit, otherwise injury may result.

When the

is displayed on the

Main display in the Full mode, the

system is centrally controlled and

the ﬁlter sign cannot be reset.
