Product Holding Bin
DHB2PT Series
542-517revC-EN Printed in USA 10/10 © 2010
Operation
Manual
Product Identification
BKFT (Breakfast) LED
MENU/ENTER Button
Upper Pan Displays
(qty. 2 or 3)
Transfer Button
REG (Regular Menu) LED
UP and DOWN Arrow
Buttons
Pan Buttons
(qty. 4, 6 or 8)
Power
On/Off
Switch
Temperature
Control
Panel
Button BarPan and Cover
PRINCE CASTLE
LOGO Button
LED Timers (tri-color)
(qty. 4, 6 or 8)
Pan and Cover Button Bar
Temperature Control Panel
Power On/Off Switch
DHB2PT-20
DHB2PT-27
Power
On/Off
Switch
Temperature
Control
Panel
Button BarPan and Cover
DHB2PT-33
LIMITED WARRANTY
This product is warranted to be free from defects in material and/or
workmanship for a period of 1 year from date of original installation, not to
exceed 18 months from the date of manufacture.
Any component which proves to be faulty in material and/or workmanship
will be replaced or repaired (at the option of Prince Castle, Inc.) without
cost to the customer for parts and labor. This warranty covers on-location
service (i.e. trip charges and/or mileage). Travel mileage is limited to
100 miles (200 Kilometers) round trip (one trip warranty) from an
authorized service agency or its sub-service agency.
This warranty is subject to the following exceptions/conditions:
• Use of any non-genuine Prince Castle parts voids this warranty.
• All labor to be performed during regular work hours. Overtime premium
(the incremental amount) will be charged to the customer.
• Damage caused by carelessness, neglect and/or abuse (e.g.,
dropping, tampering or altering parts, equipment damaged in shipment,
by fire, flood or an act of God) is not covered under this warranty.
• All problems due to operation at voltages other than that specified on
equipment nameplates are not covered by this warranty. Conversion to
correct voltage is the customer’s responsibility.
• This equipment must be serviced by Prince Castle Authorized Service
Agency or a Prince Castle Service Technician during the warranty
period.
TABLE OF CONTENTS
Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 – 10
CastleNet
®
Communications Network . . . . . . . . . . . . . . . . . . . . . . . . . 11
Factory Presets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Exploded View and Parts List (DHB2PT-20B) . . . . . . . . . . . . . . . . . . . 14
Exploded View and Parts List (DHB2PT-27B/-27BCE) . . . . . . . . . . . . 15
Exploded View and Parts List (DHB2PT-33) . . . . . . . . . . . . . . . . . . . . 16
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
355 East Kehoe Blvd. • Carol Stream, IL 60188 USA
Telephone: 630-462-8800 • Toll Free: 1-800-PCASTLE
Fax: 630-462-1460 • www.princecastle.com
