Product Holding Bin

DHB2PT Series

Calibrating Heaters

U225

Use the following steps to calibrate the individual heaters.

NOTE: Allow sufficient amount of

time for temperatures to stabilize

before starting calibration.

Press the UP or DOWN Arrow

button until the desired shelf LED

and upper (U) or lower (L) heater is

selected.

U2:30 U2:30

A. Press and hold the PRINCE CASTLE LOGO and ACTUAL

TEMP buttons for 5 seconds. The colon (:) LED indicator will

light. The temperature displayed is the actual heater

temperature sensed by the controller.

B. To clear any offset readings, press the SETPOINT button.

Take a temperature reading within the shelf near the center

of the heater surface.

Use a stand-alone temperature

meter (not supplied).

Hot surfaces. Use caution

when taking temperature

readings within the shelf.

WARNING

U2:20 U220

A. Press the UP or DOWN Arrow button until the temperature

displayed matches the reading obtained in Step 2.

B. Press the PRINCE CASTLE LOGO button to save the

temperature value and exit the Calibration Mode.

Selecting Breakfast and Regular Menus

There are six menus available:

BKFT LED ON = Menu1 or Menu6

REG LED ON = Regular2, Regular3, Regular4, or Regular5

Press and hold the MENU/ENTER button, then use the UP or

DOWN Arrow button to scroll through the 6 menus.

When scrolling, menu numbers

appear in this display.

When the desired menu is displayed, release the MENU/

ENTER button. The food products for the menu will be

displayed in the upper and lower PAN displays.

When timers for a different menu are still active, those BKFT or

REG LEDs will flash until they are all cancelled.
