•  Regulation of the Minister of Infrastructure of 12 April 2002 concerning the technical requirements of the buildings and their

location (Journal of Laws no 75, item 690 of 2002 and Journal of Laws no 109, item 1156 of 2004)

•  Standard PN-EN 13229:2002 “Inset appliances including open res red by solid fuels. Requirements and test methods”

•  Standard PN-B-02413:1991 “Heating and heating systems – Protection of open vented heating system – Requirements”

•  Standard PN-EN 1443:2005 – Chimneys. General requirements.

•  Standard PN-EN 1457-2:2012 – Chimneys – Clay/Ceramic ue liners – Part 2: Flue liners operating under wet conditions.

Requirements and test methods.

•  meets the venting system requirements, as referred to in § 150, para 9 of regulation,

•  have chimney ducts as described in § 140, par. 1 and 2 and § 145, par. 1 of the regulation,

•  allows ow of air into the replace in the amount of at least 10 m3/h per 1 kW of nominal heat output of replace – for

replaces in a sealed enclosure

In accordance with the Regulation of the Minister of Infrastructure (§ 150, para. 9 and 10), in room where are installed solid fuel

replaces with combustion air intake from the room and with gravity ue, the use of mechanical exhaust ventilation is prohibited.

This requirement does not apply to the rooms, where balanced ventilation system or over-pressure ventilation system, has been

installed.



Cast iron inserts and cast iron inserts with water jacket are appliances for solid fuel. They can be installed either as

positions and is used to control the amount of primary air fed into the burning chamber grate. A replace insert is equipped in the

regulation in the ue through the use of damper lever adjustable in position to an existing chimney draft. Operation of the replace

is by mounting it with non-combustible construction, so that the visible part of the contribution of the anterior wall of the door with

heat-resistant glass. When the door-loads of fuel as well as the observation of the ame.





The rear, side and upper walls of the burning chamber of is water jacket with a wall thickness of 25-30 mm. In upper part

of water jacked are located special pipes. The purpose of the pipes is the ensure of adequate heat transfer surface area and to

improve the circulation of water in the water space of the water jacket. During normal operation, the ue gases are “washing” the

Before connecting the replace insert read this manual and check the completeness of its equipment. To ensure safe and

economical operation of the replace is in good working order and properly adjusted in terms of the diameter as well as a good

seal duct, made according to the building rules. Before connecting the replace insert to the chimney, it is necessary to receive the

ue by a qualied chimney sweep. The chimney at the bottom, below the level of connection of the oven should be equipped with

non-combustible, double access door.

If necessary, clean the chimney. Check that the ue type is suitable for the purpose for which it is used. Check the seal or

bending is not too large and that the section allows you to make a connection via tube having the same diameter as the nozzle of

replace.


