La Nordica Padova черная [23/104] Electrical connection

ENgLIsH

The installation and the relating to the connections of the system, the commissioning and the check of the correct functioning must

be carried out in compliance with the regulations in force by authorised professional personnel with the requisites required by the

law, being national, regional, provincial or town council present in the country within which the appliance is installed, besides these

present instructions.

Installation must be carried out by authorised personnel who must provide the buyer with a system declaration of conformity and will

assume full responsibility for nal installation and as a consequence the correct functioning of the installed product.

The Product, assembled and ready for the installation, must be connected with a junction to the existing ue of the house. The

junction must be possibly short, straight, horizontal or positioned a little uphill. The connections must be tight.

material, provide suitable insulation (DIMENSIONS ACCORDING TO REGIONAL REGULATIONS).

• Make sure that there is adequate ventilation in the room where the appliance is to be installed, with particular attention to

windows and doors with tight closing (seal ropes).

• Do not install the appliance in rooms containing collective ventilation ducts, hoods with or without extractor, type B gas

appliances, heat pumps, or other appliances that, operating at the same time, can put the room in depression (ref. UNI 10683

standard).

• Make sure that the ue and the pipes to which the appliance will be connected are suitable for its operation. It is NOT allowed

the connection of various appliances to the same chimney.

• The diameter of the opening for connection to the chimney must at least correspond to the diameter of the ue gas pipe. The

opening must be equipped with a wall connection for the insertion of the exhaust pipe and a rosette.

original spare parts.

Your regular local chimney sweep must be informed about the installation of the appliance so that he can check the correct connection

to the chimney.

ELECTRICAL CONNECTION

The installation and the connection of the product has to be carried out by authorized personnel according to the current

regulations (see chapter GENERAL PRECAUTIONS). La NORDICA S.p.A. declines any responsibility for the product that has

been modied without written authorisation as well as for the use of non-original spare parts.

ATTENTION: do NOT place the electric cable nearby hot parts.

CONNECTION: Connect the electric cable to a bipolar switch with a distance of at least 3 mm between the contacts (Power source

230 V~ 50 Hz, the correct connection to the grounding system is necessary).

ammable and sensitive to heat (furniture, wood sheathings, fabrics. etc.) and from materials with ammable structure (see

Picture 4 - A). All the minimum safety distances are shown on the product data plate and lower values must not be used.

b) In front of the furnace door, in the radiation area there must be no ammable or heat-sensitive objects or material at a distance of

less than 100 cm. This distance can be reduced to 40 cm where a rear-ventilated, heat-resistant protection device is installed in

front of the whole component to protect.

c) If the product is installed on a non totally refractory oor, one must foresee a reproof background. The oors made of inammable

material, such as moquette, parquet or cork etc., must be covered by a layer of no-inammable material, for instance ceramic,

stone, glass or steel etc. (size according to regional law). The base must extend at least 50 cm at the front and at least 30 cm at

the sides, in addition to the opening of the loading door (see Picture 4 - B).

d) No ammable components (e.g. wall units) must be present above the product.

23
