ENgLIsH

especially for wood combustion (see paragraph Table). The secondary air, passing between the double glass of the re door, heats

itself starting the double combustion and keeping at the same time increasing the yield and assuring the cleaning of the glass

(see chapter NORMAL OPERATION). It is possible to get the air SECONDARY directly from outside through a exible tube

(reproof NOT furnished, see chapter EXTERNAL AIR INTAKE).

B – SMOKES control (Picture 6)

(Conversion of the cooker function LIGHTING to the OVEN COOKING ).

The smokes control can be found on the top right corner of the front side of the cooker. This control has two settings: LIGHTING

when the control bar is pulled out, the combustion gases ow around the oven and directly into the ue and up to the chimney;

OVEN COOKING when the bar is pushed to the back of the cooker, the combustion gases ow around the oven, heating it.

ATTENTION: the lighting valve must stay opened during the lighting phase only. In case it remains opened during the

normal functioning, it will cause overheating of the appliance and its components might get damaged. Moreover the fuel

consumption will be higher.

The control regulation necessary in order to obtain nominal caloric output is the following (see Cap. TECHNICAL DATA):

1A - PRIMARY air 2A - SECONDARY air TERTIARY air B - SMOKES control

PADOVA CLOSED 1/2 OPEN PRE-ADJUSTED OVEN COOKING USE function

C – OVEN light

The oven is equipped with a light, which turns on by pulling out slightly the lever C Picture 6.

To ignite the ame follow the instructions below (see Cap. IGNITION) :

• Bring the ue gas control to the LIGHTING USE position (any buttery valve placed on the ue gas exhaust pipe must also be

opened).

• Open the primary and secondary air control.

• After having started the re with small pieces of wood and waited until it is well lit.

• Bring the ue gas control to the OVEN position.

• Close any buttery valve placed on the ue gas exhaust pipe must also be opened.

The control regulation during the LIGHTING phase is the following :

1A - PRIMARY air 2A - SECONDARY air B - SMOKES control

PADOVA OPEN OPEN LIGHTING USE function

FLUE

Essential requirements for correct appliance operation:

• the internal section must preferably be circular;

• the appliance must be thermally insulated and impermeable and built with suitable materials which are resistant to

heat, combustion products and any condensation;

• there must be no narrowing and vertical passages with deviations must not be greater than 45°;

• if already used, it must be clean;

• the technical data from the instruction manual must be respected;

If the ues are of a square or rectangular section, the internal edges must be rounded with a radius of not less than 20 mm.

For the rectangular section, the maximum ratio between the sides must be ≤ 1.5.
