TECHNICAL DESCRIPTION

Wood burning cooker to t between furniture. The side external coverings are equipped with a natural aeration certies system and

act as an efcient reproof protection.

The frame of the cooker is made of STAINLESS STEEL. The air openings placed on both sides and rear side have to be kept always

unobstructed to ensure the natural air circulation into the appliance. This avoid the risks of overheating of the appliance and furniture

in-between it is installed.

ATTENTION danger of re: do not obstruct the air openings for the natural air circulation necessary to avoid overheating

of the appliance and furniture in-between it is installed. The same applies to the air openings on the base.

burning ames. Furthermore, it is thus avoided the output of sparks and smoke.

Below the oven door there is an extractable wood drawer.

ACCESSORIES

POKER GLOVE

PADOVA SERIES SERIES

The heating of the environment is made by irradiation: through the panoramic glass and the external hot surfaces of the stove,

the heat is radiated into the environment.

The cooker is equipped with controls of primary and secondary air by which it is adjusted the combustion air.

1A – PRIMARY AIR CONTROL (Picture 6)

The control knob on the re door adjusts the automatic regulator of the primary air on the low part of the cooker, through the ash

2A – SECONDARY AIR CONTROL (Picture 6)

On the hearth door there is the secondary air register. This register must be totally moved to the right in order to open the control,

e) If the product is installed on a wall made of ammable material, it is necessary to replace that part of the wall with a non-

ammable material layer, for instance ceramic, stone, glass or steel etc. The section of replacement wall has to stick out of the

product as indicated in Picture 4 - C.

The Product must always operate exclusively with the ash drawer inserted. The solid combustion residues (ash) must be collected in

a sealed, re resistant container. The Product must never be on in the presence of gaseous emissions or vapours (for example glue

for linoleum, petrol etc.). Never deposit ammable materials near the Product.

During combustion, thermal energy is released which leads to considerable heating of the surfaces, doors, handles,

controls, glass parts, the ue gas pipe and possibly the front part of the appliance. Avoid contact with these elements

b) Close the comburent air registers

c) Use carbon dioxide ( CO

2

powder ) extinguishers to put out the re

d) Request the immediate intervention of the Fire Brigade

DO NOT PUT OUT THE FIRE WITH WATER.

When the ue stops burning, have it checked by a specialist to identify any cracks or permeable points.
