TERMOROSA - DSA
7097501 79
13.1. SCHEDA TECNICA valvola termostatica VAST
Dati tecnici Materiali
Fluido: Acqua Corpo della valvola ed altre parti metalliche: Ottone forgiato
Pressione massima di esercizio: 10 bar Molla: Acciaio inox
Temperatura del uido: da 5 a 110°C Sensore: Ottone
Temperatura di apertura: 95°C (ssa) Tubo capillare: Rame
Isteresi: 6°C Guaina del tubo capillare: Acciaio
Temperatura ambiente: da 0 a 125°C Pozzetto sensore: Ottone
Capacità di usso:
2.4 m
3
/h alla pressione min. del usso
di 1 bar e tempo sensore 110°C
O-ring e guarnizioni: EPDM, NBR
Dimensioni attacco: Filettatura tubo G 3/4 ISO 228 Pulsante manuale: ABS
Lunghezza del tubo capillare: 1,3 m oppure 4m
APPLICAZIONE La valvola termostatica VAST è progettata per la protezione di caldaie a biomassa e forni. Evita il surriscaldamento della
caldaia scaricando acqua dal generatore di calore o dalla batteria di condensazione. La valvola VAST si utilizza anche per impedire il
ritorno di amma nel serbatoio del combustibile immettendo acqua in caso di temperatura eccessiva.
INSTALLAZIONE della valvola VAST sulla caldaia con scambiatore di calore di sicurezza. Prima di installare la valvola, lavare il sistema
per assicurare che non vi siano impurità che possono depositarsi sulle parti della valvola, causandone il cattivo funzionamento. Ricordare
di installare un ltro a monte della valvola. Il sensore può essere montato in qualsiasi posizione. Assicurarsi che tutto il sensore sia in
contatto con l’area tenuta sotto controllo. La freccia sul corpo della valvola indica la direzione del usso. Installando la valvola, assicurarsi
che questa sia posizionata in modo corretto. Massima coppia di serraggio per il pozzeto del sensore 30 Nm.
MANUTENZIONE Si raccomanda di vericare annualmente il corretto funzionamento della valvola, tramite personale qualicato. La prova
funzionale viene effettuata manualmente premendo il pulsante rosso che apre il usso della valvola. Il dado di serraggio del pulsante rosso
non deve essere allentato/manomesso per non causare il malfunzionamento della valvola.
13.1. Thermostatic Valve VAST TECHNICAL DATA SHEET
Technical Data Materials
Media: Water Valve body and other metal parts: forged brass
Max. Working Pressure: 10 bar Spring: stainless steel
Media temperature: 5 to 110°C Sensor: brass
Opening temperature: 9°C (xed) Capillary tube: copper
Hysteresis: 6°C. Sensor pocket: brass
Ambient temperature: O to 125°C O-rings and gaskets: EPDM, NBR
Flow capacity:
2.4 m
3
/h at min. 1 bar ow pressure
and sensor temp. 110°C
Manual button ABS
Connection size: G3/4 pipe thread ISO 228 Pulsante manuale: ABS
Length of capillary tube: 1.3 m or 4 m
APPLICATION The Thermostatic Valve VAST is designed for protection of biomass boilers and re stoves It prevents overheating of the
boiler by discharging water from heat generator or condensing coil. The valve is used also to prevent back-burning in the fuel store by
ooding the fuel in case of excessive temperature.
INSTALLATION of VAST valve on boiler with safety heat exchanger. Before installation of the valve ush the system to make sure that
there are no impurities which might deposit on the valve seat and cause malfunction. Remember to install a lter ahead of the valve. The
sensor can be mounted in any position. Make sure the whole sensor is in contact with the controlled area. The arrow on the valve body
shows direction of ow. When installing the valve, make sure it is positioned properly. Max torque for sensor pocket mounting is 30Nm.
SERVICE It is recommended to check proper function of the valve once a year by qualied personnel. Functional check is carried out
manually by depressing the red button that opens the ow on the valve. The nut fastening the red button must not be loosened as it will
cause product malfunction.
13.1. Thermostatisch gesteuerte Ventil VAST TECHNISCHE PROTOKOLLE
Technische Daten Werkstoffe
Medien: Wasser Gehäuse und andere Metallteile: Geschmiedetes Messing
Max. Betriebsdruck: 10 bar Feder: Edelstahl
Medientemperatur: 5 bis 110°C Fühler: Messing
Öffnungstemperatur: 95°C (fest) Kapillarrohr: Kupfer
Hysterese: 6°C Tauchhülse: Messing
Umgebungstemperatur: 0 bis 125°C O-Ringe und Dichtungen: EPDM, NBR
Strömungsleistung:
2.4 m
3
/h bei min. Durchussdruck von 1 bar
und Fühlertemperatur 110°C
Betätigungsknopf: ABS
Anschlussgröße: G3/4 Rohrgewinde ISO 228
Kapillarrohrlänge: 1.3 m oder 4 m
ANWENDUNG Das thermostatisch gesteuerte Ventil VAST ist für den Schutz von Biomassekesseln und Brennöfen ausgelegt. Durch
das Ablassen von Wasser aus dem Wärmeerzeuger oder der Kondensator-schlange wird eine Überhitzung vermieden. Das Ventil bietet
weiterhin Rückbrand-schutz im Brennstoffbehälter, indem es bei zu ho her Temperatur öffnet und so Wasser auf den Brennstoff gesprüht
wird.
