TERMOCAMINO BASE - DSA

6095011 - IT-EN-DE-FR 21

4. DESCRIPTION

Denition: thermo-replace according to EN 13229, The appliance works as an intermittent operating appliance.

The appliance is composed of painted and galvanised sheet steel and cast iron.

The replace is found inside the boiler, is built in 4 mm thick steel and is reinforced using welded nails. The water in the heating system

circulates in the boiler, which absorbs the heat produced in the replace.

The door with viewing window is tted on extendible ball bearing guides that guarantee the sturdy, quiet, and reliable operation of the

appliance. The counterweight for door raising is supported by two sturdy chains with respective pinions.

The device is equipped with registers of primary and secondary air, with which it is possible to adjust the combustion air. (Picture 9 at page 58)

1A- PRIMARY air register

With the air register located under the door of the hearth, it is possible to adjust the air ow through the ash drawer and the grating in

direction of the fuel. The primary air is necessary for the combustion process. In order to open the air ow, the bar must be completely

pulled out.

The ash drawer has to be emptied regularly, so that ash cannot hinder the intake of primary air for the combustion. Primary air is also

necessary to keep re live.

During the combustion of wood, the primary air register must be opened only a few, since otherwise the wood burns quickly

and the device can overheat.

2A- SECONDARY air register

BASE - DSA

5. FLUE

Essential requirements for a correct operation of the device:

• the internal section must be preferably circular;

• be thermally insulated and water-proof and produced with materials suitable to resist to heat, combustion products and

possible condensates;

• not be throttled and show a vertical arrangement with deviations not greater than 45°;

• if already used, it must be clean;

• observe the technical data of the instructions manual;

(for example 25 x 25 cm) for devices with diameter greater than 200 mm.

The draught created by the ue must be sufcient, but not excessive.

A too big ue section can feature a too big volume to be heated and consequently cause difculties in the operation of the device; to avoid

this, tube the ue along its whole height. A too small section causes a decrease of the draught.

ATTENTION: as far as concern the realisation of the ue connection and ammable materials please follow the requirements provided by

UNI 10683 standard. The ue must be properly spaced from any ammable materials or fuels through a proper insulation or an air cavity.

It is FORBIDDEN to let plant piping or air feeding channels pass in the same ue. Moreover, it is forbidden to create movable or xed

openings on the same for the connection of further other devices (Picture 5 at page 55 ).
