Hytera TC-518 [10/25] Antenna information
![Hytera TC-518 [10/25] Antenna information](/views2/1033657/page10/bga.png)
9
图1：排充组装示意图
座充连接扣
Figure 1 Assembly Diagram of Multi-unit Charger
The assembled multi-unit charger can work with HYT Six-Unit Switching Power, to charge
up to six batteries simultaneously, as shown in figure 2. Please refer to Owner’s Manual
for Six-Unit Switching Power for detailed operation procedures.
图2：六联排充充电示意图
Figure 2 Schematic Diagram of Six-Unit Charger
Antenna Information
Stubby antenna is ideal for communication within limited range. Thin and long
antenna optimizes communication coverage, and its flexible and soft characteristic
Charger Connection Latch
