Hytera TC-518 [9/25] Charging method 2

Red LED solidly glows.

Battery is charging.

Green LED solidly glows.

Battery is fully charged;

Charger is ready to charge.

Charging Method 1

Please follow the steps below:

1. Plug the AC connector of the adapter into the AC outlet socket.

2. Plug the DC connector of the adapter into the DC socket on the back of the charger.

Then charger LED glows green.

3. Place the radio with the battery attached, or the battery alone, in the charger.

4. Make sure the battery is in good contact with the charging terminals. The charging

process initiates when the red LED lights.

5. The green LED lights when the battery is fully charged (orange LED lights when the

battery is almost fully charged). Then remove the radio with the battery attached or the

battery alone from the charger.

Charging Method 2

You may connect several single-unit chargers so the combination can be used as a

multi-unit charger. To connect single-unit chargers, slide the latch on a charger into the

slot on the bottom of another one, as shown in figure 1.
