Hitachi N14DSL-R4 [51/60] English

English

(1) Press the stop lever and slide the magazine backward.

(2) Place the staples in the magazine with the prongs

facing upward.

(3) Slide the magazine back into position until the stop

lever locks into place.

NOTE

䡬 Close the magazine gently.

Using excessive force to close the magazine may

result in the joined staple strips being deformed,

preventing the magazine from being closed.

䡬 Check the magazine blade guide if it won’t close

smoothly.

HOW TO USE THE STAPLER

There are two ways to discharge staples: Single Shot, in

which the push lever is placed against the area where

the staple is to be fired first and the trigger then pulled,

and Continual Shot, in which the trigger is pulled first

and the push lever then placed against the relevant area.

The single-shot mode places the emphasis on finishing

and is used to ensure that the staple is driven into the

required place, while the continual-shot mode is used to

drive in staples repeatedly with the trigger constantly

being pulled.

The power tool is equipped with a mechanism to alternate

between single-shot and continual-shot operations to

ensure that work is carried out in the most efficient way.

Safety Devices

The power tool has been designed so that staples

cannot be fired unless both the push lever and the

trigger are simultaneously operated. In other words,

staples will not be discharged when only the trigger

is pulled, or when only the push lever (discharge

outlet) is placed against the required area. This is to

prevent the staples from being discharged when the

trigger is accidentally pulled or when the push lever

(discharge outlet) is accidently placed against

something.

䢇 Single-shot Stapling (Fig. 8)

(1) Make sure the discharge outlet is firmly placed against

the place where the staple is to be discharged.

(2) Pull the trigger to fire the staple.

(3) Withdraw the power tool and release the trigger.

NOTE

䡬 Use the single-shot mode to accurately staple the

required location.

䡬 There are cases in which subsequent stapling will

not be possible if the trigger is released halfway

through being pulled.

To correct this, remove the battery and then replace it.

䢇 Continual-shot Stapling (Fig. 9)

First pull the trigger then place the push lever

(discharge outlet) against the required area to

repeatedly fire staples.

(1) First pull the trigger.

(2) Place the push lever (discharge outlet) against the

required area to fire the staples.

(3) Withdraw the stapler with the trigger pressed, and

then repeat procedure from step (2) to repeatedly fire

staples.

Anti Blank Firing Mechanism

The stapler is equipped with an anti blank firing

mechanism to prevent blank firing when the staples

run out.

The stapler will cease to operate when eight or fewer

staples remain.

Approximately eight staples will remain after firing a

strip of staples, but replenishing the magazine with

the same staples will enable stapling to be continued.

1. Stapling procedures

WARNING

䡬 Never point the discharge outlet at people.

䡬 Make sure that work is carried out with the discharge

outlet well away from faces, hands, feet and other

parts of the body.

䡬 Do not fire staples directly onto existing staples.

䡬 Remove the battery when the stapler is not being

used and during work breaks.

䡬 When work has been completed, remove the battery,

and then remove the remaining staples.

䡬 When pulling the trigger, make sure that other fingers

are not touching the push lever.

Failure to observe this may result in injury.

NOTE

䡬 There are cases in which operations will become

sluggish if used at low ambient temperatures.

䡬 There are cases in which the staples will bend or

cracks will appear in the stapled material depending

on the hardness, thickness and combinations of the

material. Test the stapling operability before

commencing full use.

(1) Locking the trigger and removing the battery

Remove the battery from the stapler to prevent

unexpected operations. (Fig. 2)

(2) Loading staples

Load staples of a size appropriate for the job in hand

into the magazine. (Fig. 7)

(3) Attaching the battery

Place the battery onto the stapler and press on it until

it clicks into place.

(4) Releasing the lever lock

Slide the lock lever until the lock has been released.

(Fig. 5)

(5) Firing staples

Adjust the depth of the staples with the adjuster. (Fig.

10)

(6) Finishing work

When work has been finished, lock the trigger and

remove the battery, and then remove all of the staples

from the magazine.

2. How to adjust the stapling depth (Fig. 10)

WARNING

When adjusting staple depth, aim the discharge outlet

downwards and check that it is not pointing at faces,

hands, feet or other parts of the body first of all, and

then lock the trigger.

Fire a test staple, and if it is too deep adjust the depth

by rotating the adjuster to drive it shallower.

If the staple is not driven in deep enough, rotate the

adjuster to drive it deeper.

The adjuster rotation modifies the depth by up to 2

mm.

3. Using the hook

The hook is used to hang up the power tool to your

waist belt while working.

CAUTION:

䡬 When using the hook, hang up the power tool firmly

not to drop accidentally.

If the power tool is dropped, it may lead to an accident.

05Eng_N14DSL_NE 9/6/12, 11:1050
