Hitachi W6VA4NA [6/49] English

English

PRIOR TO OPERATION

1. Power source

Ensure that the power source to be utilized conforms

to the power requirements specified on the product

nameplate.

2. Power switch

Ensure that the power switch is in the OFF position. If

the plug is connected to a power receptacle while the

pow er switch is in the ON position, the power tool

will start operating immediately, w hich could cause a

serious accident.

3. Extension cord

When the work area is removed from the power

source, use an extension cord of sufficient thickness

and rated capacity. The extension cord should be

kept as short as practicable.

4. Confirm the direction of bit rotation (Fig. 1)

The bit rotates clockwise (viewed from the rear

side) w hen the reversing switch lever is set to the

“ R” side position. When the lever is set to the “ L”

side position, the bit rotates counterclockwise and

can be used to loosen and remove screws.

5. Adjusting the tightening depth (Fig. 2)

The tightening depth can be adjusted by turning

locator right and left click feeling.

(1) For hex-head screws:

Mount a hex-head screw on the hex-socket and set

the distance between the sub-stopper end and the

screw head neck to 1–1.5 mm, as shown in Fig. 3.

(2) For drywall screws:

Mount a drywall screw on the bit, and set the

distance between the sub-stopper end and the screw

head to 1.5–2 mm, as shown in Fig. 4.

(3) For cross-recessed self-drilling screws:

Mount a self-drilling screw on the bit, and set the

distance between the sub-stopper end and the screw

head bottom to 1–1.5 mm, as shown in Fig. 5.

6. Mounting the bit

For details, refer to the item “ M ounting and

dism ounting the bit” .

MOUNTING AND DISMOUNTING THE HEX-

SOCKET OR THE BIT

1. Dismounting the hex-socket (Fig. 6)

(1) While rotating the Sub-Stopper pull it out from the

locator.

(2) Remove the hex-socket, hold it with the opposite

side of bit by hand or vise and pull out the bit with

pliers.

2. Dismounting the bit (Fig. 7)

Remove sub-stopper (G) as the same manner of

hex-head socket and remove the bit holder, then

pull out the bit w ith pliers.

3. Dismounting the bit (Fig. 8)

Remove the sub-stopper (F) as the sam e manner

of hex-head socket and remove the bit holder, then

pull out the bit w ith pliers.

4. Mounting the hex-socket or the bit

Install the bit in the reverse order to removal.

HOW TO USE THE SCREW DRIVER

1. Switch operation and rotational speed adjustment

Bit rotational speed can be adjusted between 0 –

6000 min

-1

(W6VM) or 0 – 4500 min

-1

(W6V4) or

0 – 3000 min

-1

(W6VA4) or 0 – 2600 min

-1

(W6VB3)

or 0 – 1700 min

-1

(W8VB2) varying the degree by

which the trigger switch is pulled. Rotational speed

increases as the trigger switch is pulled, and reaches

a maximum speed of 6000 min

-1

(W6VM) or 4500

min

-1

(W6V4) or 3000 min

-1

(W6VA4) or 2600

min

-1

(W6VB3) or 1700 min

-1

(W8VB2) when the

trigger switch is pulled fully.

To facilitate continuous operation, pull the trigger

switch and depress the sw itch stopper. The switch

will then remain ON even when the finger is released.

By pulling the trigger switch again, the switch

stopper disengages and the switch is turned OFF

when the trigger sw itch is released.

2. Screw Driver operation

When the switch is turned ON, the motor starts to

run but the hex-socket (or the bit) does not rotate.

Attach the hex-socket to the screw head groove,

and push the Screw Driver against the screw. The

hex-socket then rotates and tightens the screw.

CAUTION

Ensure that the Screw Driver is held truly

perpendicular to the head of the screw.

If held at an angle, the driving force will not be

fully transferred to the screw, and the screw head

and/or hex-socket will be damaged. Hex-socket

rotation stops when pushing force is released.

3. Direction of hex-socket rotation

The hex-socket rotates clockwise (viewed from the

rear side) when the reversing switch lever is set

to the “ R” side position. When the lever is set to

the “ L” side position, the hex-socket rotates counter-

clockw ise, and can be used to loosen and remove

screws.

CAUTION

Never change the direction of hex-socket (or bit

holder) rotation while the motor is running. To do

so would seriously damage the motor. Turn the

pow er switch OFF before changing the direction

of hex-socket (or bit holder) rotation.

MAINTENANCE AND INSPECTION

1. Inspecting the hex-socket (or bit)

Since continued use of a w orn hex-socket (bit) will

damage screw heads, replace the hexsocket (bit)

with a new one as soon as excessive wear is

noticed.

2. Inspecting the mounting screws

Regularly inspect all mounting screws and ensure

that they are properly tightened. Should any of the

screws be loose, retighten them immediately. Failure

to do so could result in serious hazard.

3. Maintenance of the motor

The motor unit winding is the very ” heart” of the

pow er tool. Exercise due care to ensure the winding

does not becom e damaged and/or wet with oil or

water.
