4
English
APPLICATIONS
Rotation and hammering function
○ Drilling anchor holes
○ Drilling holes in concrete
Hammering only function
○ Crushing concrete, chipping, digging, and squaring
(by applying optional accessories)
SPECIFICATIONS
The specifi cations of this machine are listed in the Table on
page 102.
NOTE
Due to HITACHI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
MOUNTING AND OPERATION
Action Figure Page
Inserting SDS-max tools 1 103
Removing SDS-max tools 2 103
Changing tool direction 3 103
Selecting the operating mode 4 103
Switching on and off 5 103
About the power lamp 6 104
Speed change 7 104
Install the stopper 8 104
Using tapershank adapter 9
105
Removing tapershank adapter 10
105
Mounting core bit 11
105
Mounting guide plate and center pin 12
105
Selecting accessories* –
106, 107
* For detailed information regarding each tool, contact a
Hitachi authorized service center.
Warming up (Fig. 13)
The grease lubrication system in this unit may require
warming up in cold regions.
Position the end of the bit so makes contact with the
concrete, turn on the switch and perform the warming
up operation. Make sure that a hitting sound is produced
and then use the unit.
CAUTION
When the warming up operation is performed, hold the
side handle and the main body securely with both hands
to maintain a secure grip and be careful not to twist your
body by the jammed drill bit.
ABOUT THE PROTECTION
FUNCTION
This tool has a built-in protection circuit for preventing
damage to the unit in the event of an abnormality. Depending
on the nature of the abnormality, the display lamp will fl ash
as shown in Table 1 and the unit will cease to operate. In
such cases, verify the problem indicated by the fl ashing and
take whatever steps are necessary to correct the problem.
NOTE
Repair may be required if the display lamp continues to
fl ash after taking all necessary steps to correct the problem.
If the problem persists, please arrange for repairs.
Table 1
Display
lamp
fl ashing
Cause Solution
Flash
Internal temperature
has risen beyond
the unit’s specifi ed
temperature.
(Temperature
increase protection
function)
Turn off the unit and
allow it to cool down
for about 15 minutes.
When the temperature
goes down, the display
lamp will stop fl ashing
and remain lit to
indicate that the unit is
ready for use.
Flash
Excessive pressure
applied to the tool
has resulted in an
overload.
(Overload
protection function)
Press the rotation
speed selector switch
to recover. Try to avoid
tasks that will apply
excess pressure to
the unit.
Flash
Tool is connected
to a power source
whose voltage is
either too high or
too low.
(Circuit protection
function)
Connect the unit to a
power supply matching
the input voltage
specifi ed on the
nameplate. Press the
rotation speed selector
switch to recover.
Flash
Sensor signal read
error.
(Control monitoring
function)
Press the rotation
speed selector switch
to recover. Repair may
be required if this error
continuously occurs.
GREASE REPLACEMENT
This Rotary Hammer is of full air-tight construction to protect
against dust and to prevent lubricant leakage.
Therefore, this Rotary Hammer can be used without
lubrication for long periods. Replace the grease as described
below.
Grease Replacement Period
After purchase, replace grease after every 6 months of
usage. Ask for grease replacement at the nearest authorized
Service Center.
MAINTENANCE AND INSPECTION
1. Inspecting the drill bits
Since use of a dull tool will cause motor malfunctioning
and degraded effi ciency, replace the drill bit with new
ones or resharpen them without delay when abrasion is
noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool.
Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
4. Replacing supply cord
If the replacement of the supply cord is necessary, this
has to be done by the manufacturer of this agent in order
to avoid a safety hazard.
