1716
SE 3.6 LA 036
..................... 4131 84 02...
...000001-999999
.............................3 mm
.............................6 mm
..........................4,5 mm
.........................200 min
-1
.........................600 min
-1
..........................4,5 Nm
..........................6,5 Nm
.............................140
..........................3,6 V
......................0,575 kg
...........................55 dB (A)
.......................< 2,5 m/s
2
..........................1,5 m/s
2
.......................< 2,5 m/s
2
..........................1,3 m/s
2
............................... ...............................3,6 V
............................... ...............................1,8 A
............................... .........................50-100 mA
............................... ..........................ca. 45 min
............................... ..........................ca. 65 min
............................... ..........................ca. 60 min
............................... ..............................285 g
water. In case of eye contact rinse thoroughly for at least 10
minutes and immediately seek medical attention.
The following battery packs can be charged with this
charger:
voltage battery rating No. of
(of storage battery) battery
cells
3.6 V SB 3.6 ≤ 1.4 Ah 3
3.6 V SM 3.6 ≤ 2.0 Ah 3
3.6 V SL 3.6 ≤ 1.5 Ah 1
Do not try to charge non-chargeable batteries with this
charger.
No metal parts must be allowed to enter the battery section
of the charger (short circuit risk).
Never break open battery packs and chargers and store
only in dry rooms. Keep dry at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new
one.
Before use check machine, cable, and plug for any
damages or material fatigue. Repairs should only be carried
out by authorised Service Agents.
This appliance is not intended to
be used or cleaned by persons
with reduced physical, sensory or
mental capabilities, or lack of
experience or knowledge, unless
they have been given instructions
concerning the safe use of the
appliance by a person legally
responsible for their safety. They
should be supervised whilst using
the appliance. Children shall not
use, clean or play with this
appliance, which when not in use
should be secured out of their
reach.
SPECIFIED CONDITIONS OF USE
The battery drill/screwdriver is designed for drilling and
screwdriving for independent use away from mains supply.
The quick charger can charge AEG batteries System SE36
from 3,6 V.
Do not use this product in any other way as stated for
normal use.
MAINS CONNECTION LA 036
Connect only to single-phase a.c. current and only to the
system voltage indicated on the rating plate. It is also
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that the product
described under “Technical Data” fulfi lls all the relevant
provisions of the directives 2011/65/EU (RoHs), 2014/30/
EU, 2006/42/EC and the following harmonized standards
have been used:
EN 60745-1:2009 + A11:2010
EN 60745-2-1:2010
EN 60745-2-2:2010
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:1997 + A1:2001 + A2:2008
EN 50581:2012
Winnenden, 2016-03-29
Alexander Krug
Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
ADVICE FOR OPERATION
Never use the gear switch whilst the machine is operating.
Only use the switch when the machine is at a standstill.
BATTERIES
New battery packs reach full loading capacity after 4 - 5
chargings and dischargings. Battery packs which have not
been used for some time should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the
performance of the battery pack. Avoid extended exposure
to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept
clean.
For an optimum life-time, after use, the battery packs have
to be fully charged.
To obtain the longest possible battery life remove the battery
pack from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C
and away from moisture
Store the battery packs in a 30% - 50% charged condition
Every six months of storage, charge the pack as normal.
General note concerning NiMH batteries: The capacity of
the battery is reduced when the temperature falls below
-10°C. Long-term storage at temperatures higher than
+40°C may have negative effects on the capacity of the
battery.
CHARACTERISTICS
After inserting the battery into the reception of the charger
the battery will automatically be charged (yellow control
lamp is illuminated continuously)
When a hot or cold battery pack is inserted into the charger
(fl ashing red lamp), charging will begin automatically once
the battery reaches the correct charging temperature (NiCd/
NiMh -5°C...50°C, Li-Ion 0°C...55°C).
Charging time varies depending on the battery temperature,
charge needed and the type of battery pack being charged.
As soon as charging is completed, the charger switches
over to ”trickle” charge to maintain the full capacity (green
control lamp is illuminated continuously)
It is not necessary to remove the battery after charging. The
battery can be stored permanently in the charger without the
danger of being overcharged.
If both LEDs fl ash, either the battery has not been
completely mounted or there is a fault in the battery or the
ENGLISHENGLISH
TECHNICAL DATA
Production code.......................................................................
Drilling capacity in steel ...........................................................
Drilling capacity in wood ..........................................................
Wood screws (without pre-drilling) ..........................................
No-load speed, 1st gear ..........................................................
No-load speed, 2nd gear .........................................................
Torque
Low torque *1 .......................................................................
High torque *1 .......................................................................
Screwing capacity with one fully charged battery (2.0 Ah): *2
4x30 Soft wood .....................................................................
Battery voltage.........................................................................
Weight according EPTA-Procedure 01/2003 ...........................
Noise/vibration information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K = 3 dB(A)) .......................................
The noise level when working can exceed 85 dB (A).
Wear ear protectors!
Total vibration values (vector sum in the three axes)
determined according to EN 60745.
Vibration emission value a
h
Drilling into metal ..................................................................
Uncertainty K ........................................................................
Screwing ...............................................................................
Uncertainty K ........................................................................
Voltage range ..........................................................................
Quick charge current NiCd / NiMH / Li-Ion ..............................
Maintaining charge ..................................................................
Battery charging time NiCd 1,4 Ah ..........................................
Battery charging time NiMH 2,0 Ah .........................................
Battery charging time Li-Ion 1,5 Ah .........................................
Weight according EPTA-Procedure 01/2003 ...........................
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and instructions
may result in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Wear ear protectors. Exposure to noise can cause hearing
loss.
Hold power tool by insulated gripping surfaces, when
performing an operation where the fastener may
contact hidden wiring. Fasteners contacting a "live" wire
may make exposed metal parts of the power tool "live" and
could give the operator an electric shock.
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring. Cutting accessory contacting
a "live" wire may make exposed metal parts of the power
tool "live" and could give the operator an electric shock.
Always wear goggles when using the machine. It is
recommended to wear gloves, sturdy non slipping shoes
and apron.
Sawdust and splinters must not be removed while the
machine is running.
When working in walls ceiling, or fl oor, take care to avoid
electric cables and gas or waterpipes.
Remove the battery pack before starting any work on the
machine.
Do not dispose of used battery packs in the household
refuse or by burning them. AEG Distributors offer to retrieve
old batteries to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
Use only System SE36 chargers for charging System SE36
battery packs. Do not use battery packs from other systems.
Battery acid may leak from damaged batteries under
extreme load or extreme temperatures. In case of contact
with battery acid wash it off immediately with soap and
*1 Measured according to AEG norm N 877318
*2 The values stated are reference values (2nd gear). Actual values might differ, depending on the material and quality of the
screws.
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the vibration emission may differ. This may signifi cantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
