32 887-001_v01
Operating the mincing set
Put the following elements into the mincing chamber:
1
Feed screw with the coupling towards the middle.
2
Fit the knife (4) onto the pin of the scroll (3).
3
Put the screen so that the chamber’s protrusion enters
the rut of the screen.
4
Tighten all the elements of the mincing set – until home.
5
Put the assembled unit onto the drive unit and turn into
the position, when you hear click of the safety lock.
6
Put the food tray onto the mincing chamber.
Operating the sausage stuer
Put the following elements into the mincing chamber:
1
Feed screw with the coupling towards the middle.
2
Separator on the feed screw end.
3
The sausage stuffer.
4
Tighten all the elements of the mincing set – until home.
5
Put the assembled unit onto the drive unit and turn into
the position, when you hear click of the safety lock.
6
Put the food tray onto the mincing chamber.
Before placing the sausage intestine (intestine wrapper)
soak it in warm water for about 10 minutes.
Put the wet sausage intestine onto the sausage stuffer,
●
paying attention not to cover the venting holes within the
sausage stuffer.
The meat mass lling the intestine cannot be
“too rare”. Large amount of uids can cause
their leakage and permeating to the interior of
the mincing machine.
Shredder
1
Fine grating disc
2
Coarse grating disc
3
Slicing disc
4
Pureeing disc
5
Locking tab
6
Body
7
Tray
8
Pusher
The shredder is equipped with two drums to grate into small
and bigger chips (cheese, carrot, celery, baked beetroots,
etc.). The third grating drum (slicing drum) is used to grate
vegetables (potatoes, onion, cucumbers, etc.). The fourth
grating drum (pulping drum) is used to mash vegetables
(potatoes, beetroots, etc) and fruit.
D
G
E
Operating the shredder
1
Recline the catch and put one of the drums with the
clutch facing the middle of the chamber.
2
Snap the catch.
3
Assemble the chamber of the shredder just as like
mincing chamber.
Cut large products into smaller elements, which you can
●
easily put into the mincing chamber.
Do not mash soft fruits containing stones.
●
When the work is nished pull the power cord out from
●
the network supply socket.
Remove the food remaining in the shredder chamber or
●
on the grater with a wooden spoon.
Blades of the drums do not require any
regeneration.
Pasta sieve set
Excellent pasta dough
300 g of our, 10 yolks from medium size eggs, 3 spoons of
olive oil, pepper (as much as you want), milled red pepper
(as much as you want), dried mint (as much as you want).
Work together until you have a smooth dough. The well
prepared dough should be “rm”. Don’t add any water
during dough preparation! It is recommended to cool down
such prepared dough in a freezer for approximately 10 min.
Immerse the pasta sieves in hot water for a moment before
usage.
1
Put the selected sieve inside the milling cavity.
2
Assemble the whole milling set on the motor part.
Separate small pieces of the dough (walnut size) and
●
carefully put them into the milling cavity inlet.
You can put the next piece of pastry to the
milling cavity, only when the previous one has
been taken in by the worm. Use the pusher
during pastry inserting.
You can powder the pasta emerging from the machine
●
with our, to prevent getting stuck together.
You can divide the pasta emerging from the machine,
●
cutting it at the sieve. You can also leave the whole
output to get dried and break into smaller pieces before
usage.
3
To unblock the holes of the sieve you should use the
attached pusher.
When squeezing out the pasta the device can
operate without any break not longer than
2 min.
Next pasta squeezing is possible after complete
motor cooling – see the operation manual.
F
H
