Zelmer 887.84 Lime [29/30] Cookies forming set
![Zelmer 887.84 Lime [29/30] Cookies forming set](/views2/1036745/page29/bg1d.png)
33
887-001_v01
Cookies forming set
Shortcake cookies
500 g of our, 1 bar of butter, 1 glass of sugar, 1 egg,
1 package of vanilla sugar.
Mix the butter with sugar and vanilla sugar. Add an egg and
our to it and mix altogether. Put such prepared pastry to the
freezer to cool it down for about 40 min.
1
Place the cookies forming set inside the cavity.
2
Assemble the whole milling set on the motor part.
Cut the pastry into pieces and put them into the milling
●
cavity inlet.
You can put the next piece of pastry to the
milling cavity only when the previous one has
been taken in by the worm. Use the pusher
during pastry inserting.
You can form free the length of the cookies. Put
●
the cookies onto bakingsheet and bake with oven
temperature 180°C.
The device with milling cavity and cookies
forming set assembled can operate without any
break not longer than 10 min.
Juicer
The juicer is an accessory for some types of mincers.
It allows squeezing juice from fruits such as: raspberries,
currants, strawberries, gooseberry and additionally from
grapes and tomatoes. Berry fruits such as currants can
be squeezed with stalks. Fruits with large stones, such as
plums, cherries etc. can be squeezed in the appliance after
removing the stones.
Parts of the juicer:
1
Chamber
2
Worm
3
Body
4
Nut
5
Juice channel
6
Adjusting screw
7
Bowl (from the mincer unit)
8
Pusher (from the mincer unit)
9
Screen – 2 pieces
No. 1 – smaller openings
No. 2 – larger openings
10
Large sealing ring for the body (3)
11
Small sealing ring for the worm (2)
12
Hook
13
Brush
Use only the pusher to push fruits (8).
I
K
PREPARING THE JUICER FOR OPERATION
AND ITS OPERATION
1
Make sure that the sealing rings (10) and (11) are tted
onto the body (3) and the worm (2). If not, insert them into the
sealing grooves in these elements (the body and the worm).
2
Insert the screen (9) into the body (3) and press rmly
home.
In order to remove the sieve (9) out of the body
(3), it is helpful to use the hook (12). Put the
shorter end of the hook (12) into the hole of the
sieve (9), and pull the sieve (9) outside.
3
Insert the worm (2) into the chamber (1).
4
Insert the body with the screen onto the worm making
sure that the sieve faces downwards , and the positioning
slot ts into the protrusion in the chamber.
5
Screw on the nut (4) to attach the body to the chamber (1).
6
Screw the adjusting screw (6) into the body (3).
7
Slide the juice channel (5) over the adjusting screw until
it snaps on the body (3) – “click”.
8
Attach the assembled juicer to the drive unit in the same
way as the mincer body.
9
Insert the bowl (7) and the pusher (8) – from the mincer
unit – onto the feeding tube.
10
Place the appropriate dishes for the juice and pomace
under the outlet of the juice channel (5) and the adjusting
screw (6).
11
Plug in the appliance.
12
Turn the appliance on by means of the switch button,
and then feed the fruit, pushing with the pusher.
In order for the juice squeezing process to run
properly do not screw the adjustment screw
too deeply in the initial operation phase. �fter
assessing the amount of juice in the processed
fruits, adjust the screw in order to obtain an
adequate effectiveness and to avoid clogging
the appliance.
Observe the pomace dryness during squeezing. If it
●
is too dry, unscrew the adjusting screw (6), to avoid
clogging the appliance with the pomace.
The screw adjustment depends on the type of
processed fruits, in case of juicy and ripe fruits
adjust the screw deeper, and for fruits that
are not as juicy, the level of screw adjustment
should be lower.
If the screw adjustment does not provide an
adequate squeezing effectiveness, you can
process the pomace once again.
The clogging of the chamber outlet (in the
adjustment screw (3)) with the pomace of juicy
fruits can cause the ooding of the drive unit.
Unplug the appliance if the chamber outlet becomes
●
clogged. Pay special attention on the juice squeezing
L
