9
• Holding and guiding the tool @
 

- 3 (can be adjusted
as illustrated)
- keep the ventilation slots uncovered
- do not apply too much pressure on the tool; let the tool
do the work for you

• For drilling in concrete or stone a steady pressure on the
drill is required
• When drilling ferrous metals
- pre-drill a smaller hole, when a large hole is required
- lubricate drill bit occasionally with oil
• When turning in a screw at/near the cross cut end or an
edge of wood, pre-drill a hole in order to avoid cracking of
the wood

• Always keep tool and cord clean (especially the
ventilation slots)
 
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool  together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skilmasters.com)

• 

(only for EU countries)
- in observance of European Directive 2002/96/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol # will remind you of this when the need for
disposing occurs

• We declare under our sole responsibility that this product
is in conformity with the following standards or
standardized documents: EN 60745, EN 61000,
EN 55014, in accordance with the provisions of the
directives 2006/95/EC, 2004/108/EC, 2006/42/EC
• : SKIL Europe BV (PT-SEU/PJE),
4825 BD Breda, NL
ÊÆÇιÆ¼½ÊÄÇÇÌ
Á»½ʽËÁ¼½ÆÌ
ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿
ÍÊÇȽƓˁ˅ʿ˂ʽ¼¹Ɠ
¹ÆÊÇÅŽĽÆ
ÈÈÊÇιÄ¹Æ¹¿½Ê
21.12.2010

• Measured in accordance with EN 60745 the sound
pressure level of this tool is 94 dB(A) and the sound
power level 105 dB(A) (standard deviation: 3 dB), and the
vibration ✱(hand-arm method; uncertainty K = 1.5 m/s²)
✱when drilling in metal 5.6 m/s²
✱when impact drilling in concrete 13.7 m/s²
• The vibration emission level has been measured in
accordance with a standardised test given in EN 60745; it
may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for dierent applications, or with dierent
or poorly maintainted accessories, may signicantly
 the exposure level
- the times when the tool is switched o or when it is
running but not actually doing the job, may signicantly
 the exposure level
 




Содержание

Похожие устройства

Holding and guiding the tool I while working always hold the tool at the grey coloured grip area s always use auxiliary handle F can be adjusted as illustrated keep the ventilation slots uncovered do not apply too much pressure on the tool let the tool do the work for you C DECLARATION OF CONFORMITY We declare under our sole responsibility that this product is in conformity with the following standards or standardized documents EN 60745 EN 61000 EN 55014 in accordance with the provisions of the directives 2006 95 EC 2004 108 EC 2006 42 EC Technical file at SKIL Europe BV PT SEU PJE 4825 BD Breda NL Arno van der Kloot Vice President Operations Engineering APPLICATION ADVICE For drilling in concrete or stone a steady pressure on the drill is required When drilling ferrous metals pre drill a smaller hole when a large hole is required lubricate drill bit occasionally with oil When turning in a screw at near the cross cut end or an edge of wood pre drill a hole in order to avoid cracking of the wood JanTrommelen Approval Manager SKIL Europe BV 4825 BD Breda NL 21 12 2010 NOISE VIBRATION Measured in accordance with EN 60745 the sound pressure level of this tool is 94 dB A and the sound power level 105 dB A standard deviation 3 dB and the vibration hand arm method uncertainty K 1 5 m s2 when drilling in metal 5 6 m s2 when impact drilling in concrete 13 7 m s2 The vibration emission level has been measured in accordance with a standardised test given in EN 60745 it may be used to compare one tool with another and as a preliminary assessment of exposure to vibration when using the tool for the applications mentioned using the tool for different applications or with different or poorly maintainted accessories may significantly increase the exposure level the times when the tool is switched off or when it is running but not actually doing the job may significantly reduce the exposure level I protect yourself against the effects of vibration by maintaining the tool and Its accessories keeping your hands warm and organizing your work patterns MAINTENANCE SERVICE Always keep tool and cord clean especially the ventilation slots I disconnect the plug before cleaning If the tool should fail despite the care taken in manufacturing and testing procedures repair should be carried out by an after sales service centre for SKIL power tools send the tool undismantled together with proof of purchase to your dealer or the nearest SKIL service station addresses as well as the service diagram of the tool are listed on www skilmasters com ENVIRONMENT Do not dispose of electric tools accessories and packaging together with household waste material only for EU countries in observance of European Directive 2002 96 EC on waste of electric and electronic equipment and its implementation in accordance with national law electric tools that have reached the end of their life must be collected separately and returned to an environmentally compatible recycling facility symbol will remind you of this when the need for disposing occurs 9
