5.5.3 NULL Message

The NULL message returned from the monitor is used in the following cases;

To tell the controller that the monitor does not have any answer to give to the host (not

ready or not expected)

A null message will be returned by the monitor if the “Start Proof of Play” command is sent

and the monitor has already started Proof of Play.

A null message will be returned by the monitor if the “Stop Proof of Play” command is sent

and the monitor has not started Proof of Play.

Complete "NULL Message" command packet as follows;

01h-30h-30h-41h-42h-30h-34h-02h-42h-45h-03h-CHK-0Dh

SOH-'0'-'0'-'A'-'B'-'0'-'4'-STX-'B'-'E'-ETX-CHK- CR

STX

Command code

ETX

'B' 'E'
