![Nec MultiSync UN551VS [43/139] Carbo n footprint](/views2/1375531/page43/bg2b.png)
(43/43)
Item OP
code
page
OP code Parameter Remarks
PIP ON/OFF
STILL ON/OFF
02h 72h 0: No mean
1: Off
2: PIP
3: POP
4: STILL
5: PICTUR BY PICTURE
- ASPECT
6: PICTURE BY PICTURE
- FULL
PIP INPUT 02h 73h 0: No mean
1: VGA
2: RGB/HV
3: DVI
4: HDMI (Set only)
5: VIDEO
7: S-VIDEO
12(0Ch): Y/Pb/Pr
13(0Dh): OPTION
14(0Eh): Y/Pb/Pr2
(SCART)
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI
18(12h): HDMI2
128(80h): DPORT3
This operation
has limitation of
selection.
Please refer to
the monitor
instruction
manual.
STILL CAPTURE 02h 76h 0: OFF
1: CAPTURE
Momentary
SIGNAL INFORMATION 02h EAh 0: No mean
1: OFF
2: ON
AUTO SETUP 00h 1Eh 0: No mean
1: Execute
Momentary
TV-CHANNEL UP/DOWN 00h 8Bh 0: No mean
1: UP
2: DOWN
This operation
requires
support
ed option
TV tuner.
TEMPE RATU RE S ENSO R
SELECT TEMPERATURE SENSOR 02h
78h 0: No mean
1: SENSOR #1
2: SENSOR #2
3: SENSOR #3
READOUT A TEMPERATURE 02h 79h Returned value is 2's
complement.
Refer to section 6.2
Read only
CARBO N FO OTPR INT
READOUT CARBON FOOTPRINT
(g)
10h 10h 0:
|
999(3E7h):
Read only
READOUT CARBON FOOTPRINT
(kg)
10h 11h 0:
|
65535(FFFFh):
Read only
READOUT CARBON USAGE
(g)
10h 26h 0:
|
999(3E7h):
Read only
READOUT CARBON USAGE
(kg)
10h 27h 0:
|
65535(FFFFh):
Read only
