Item OP
code
page
OP code Parameter Remarks
INPUT 00h 60h 0: No mean
1: VGA
2: RGB/HV
3: DVI
4: HDMI (Set only)
5: VIDEO
7: S-VIDEO
12(0Ch): Y/Pb/Pr
13(0Dh): OPTION
14(0Eh): Y/Pb/Pr2
(SCART)
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI
18(12h): HDMI2
128(80h): DPORT3
AUDIO INPUT 02h 2Eh 0: No mean
1: IN1
2: IN2
3: IN3
4: HDMI
6: OPTION
7: DPORT
8: DPORT2
9: DPORT3
10(0Ah): HDMI2
VOLUME UP/DOWN 00h 62h 0: whisper
|
100(64h): loud
MUTE 00h 8Dh 0: UNMUTE(Set only)
1: MUTE
2: UNMUTE
SCREEN MUTE 10h B6h 0: No mean
1: SCREEN MUTE ON
2: SCREEN MUTE OFF
MTS 02h 2Ch 0: No mean
1: Main
2: Sub
3: Main + Sub
This operation
requires
supported option
TV tuner.
SOUND 02h 34h 0: No mean
1: Off
2: ON
Same as
‘SURROUND’
PICTURE MODE 02h 1Ah 0: No mean
1: sRGB
3: HIGHBRIGHT
4: STANDARD
5: CINEMA
8: CUSTOM1
9: CUSTOM2
sRGB:
PC mode only
CINEMA:
A/V mode only
ASPECT 02h 70h 0: No mean
1: NORMAL
2: FULL
3: WIDE
4: ZOOM
6: DYNAMIC
7: 1:1 (Off/dot by dot)
WIDE:
A/V mode only
