Item OP
code
page
OP code Parameter Remarks
SENSOR1 10h E0h/E1h E0h: Set centigrade
0 – 65535(FFFFh)
E1h: Set
offset from max.
value
0 – 10(0Ah)
SENSOR2 10h E2h/E3h E2h: Set centigrade
0 – 65535(FFFFh)
E3h: Set
offset from max.
value
0 – 10(0Ah)
SENSOR3 10h E4h/E5h E4h: Set centigrade
0 – 65535(FFFFh)
E5h: Set
offset from max.
value
0 – 10(0Ah)
SCREEN SAVER GAMMA 02h DBh 0: No mean
1: OFF
2: ON
BACKLIGHT 02h DCh 0: No mean
1: OFF
2: ON
MOTION
INTER
VAL
02h DDh 0: OFF(0s)
|
90(5Ah): 900s
10s/step
ZOOM 10h 35h 0 : 95%
|
5 : 100%
|
10(0Ah) : 105%
SIDE BORDER COLOR 02h DFh 0: Black
|
100(64h): White
CHANGE PASSWORD N/A
SECURITY Refer to Chapter 22
RESET
(DISPLAY PROTECTION)
02h CBh 0: No mean
9: Reset
Display Protection
category
Momentary
EXTER NAL CONT ROL
IP ADDRESS SETTING N/A
MAC ADDRESS Refer to Chapter 23
LAN POWER 10h D3h 0: No mean
1: OFF
2: ON
DDC/CI 10h BEh 0: No mean
1: OFF
2: ON
PING N/A
IP ADDRESS RESET N/A
RESET
(EXTERNAL CONTROL)
02h CBh 0: No mean
12(0Ch): Reset External
Control Category
Momentary
ADVAN CED OPTI ON1
INPUT DETECT 02h 40h 0: FIRST DETECT
1: LAST DETECT
2: NONE
3: VIDEO DETECT
4: CUSTOM DETECT
CUSTOM
DETECT
PRIORITY1 10h 2Eh 0: No mean
1: VGA
2: RGB/HV
3: DVI
4: HDMI (Set only)
