(40/40)
Item OP
code
page
OP code Parameter Remarks
DisplayPort 10h F1h/F2h Select target DPORT.
(F1h)
0: No mean
1: DPORT
2: DPORT2
3: DPORT3
Read / Write status of
target DPORT.(F2h)
0: No mean
1: 1.1a
2: 1.2
HDMI SIGNAL 10h 40h 0: No mean
1: EXPAND
2: RAW
DEINTERLACE 02h 25h 0: No mean
1: Off
2: ON
COLOR SYSTEM 02h 21h 0: No mean
1: NTSC
2: PAL
3: SECAM
4: AUTO
5: 4.43NTSC
6: PAL-60
OVER SCAN 02h E3h 0: No mean
1: OFF
2: ON
OPTION
SETTING
OPTION POWER 10h 41h 0: OFF
1: ON
AUDIO 10h B0h 0: No mean
1: ANALOG
2: DIGITAL
INTERNAL
PC
OFF
WARNIN
G
10h C0h 0: No mean
1: OFF
2: ON
AUTO
OFF
10h C1h 0: No mean
1: OFF
2: ON
START
UP PC
10h C2h 0: No mean
1: Execute
FORCE
QUIT
10h C3h 0: No mean
1: Execute
120Hz 10h 87h 0: No mean
1: ON
2: OFF
TOUCH
PANEL
STANDBY 10h C4h 0: No mean
1: OFF
2: ON
PC SOURCE 10h C5h 0: No mean
1: AUTO
2: EXTERNAL PC
RESET
(ADVANCED OPTION1)
02h CBh 0: No mean
10(0Ah): Reset Advanced
option1 category
Momentary
ADVAN CED
AUTO
DIMMING
AUTO BRIGHTNESS 02h 2Dh 0: OFF
1: ON
ROOM LIGHT SENSING
10h C8h 0: No mean
1: OFF
2: MODE1
3: MODE2
BACKLIGHT
SETTING
MAX
LIMIT
10h C9h 0 – 100(64h)
