(37/37)
Item OP
code
page
OP code Parameter Remarks
V SCAN REVERSE
11h 04h 0: No mean
1: NONE
2: AUTO
3: MANUAL
Available on
X464UN, X554UN,
X464UNV, X554UNS
MANUAL 11h 05h 0: No mean
1: NON REVERSE
2: REVERSE
Available on
X464UN, X554UN,
X464UNV, X554UNS
This command is
used when
V SCAN
REVERSE is set
as
“MANUAL”.
TILE MATRIX MEM 10h 4Ah 0: No mean
1: COMMON
2: INPUT
AUTO TILE MATRIX SETIP Refer to chapter 19
POWER ON DELAY 02h D8h 0: Off (0sec)
|
50(32h): 50sec
LINK TO ID 10h BCh 0: No mean
1: OFF
2: ON
VIDEO OUT SETTING 10h EAh 0: No mean
1: ON
2: OFF
POWER INDICATOR 02h BEh 0: No mean
1: ON
2: OFF
SETTING COPY Refer to Chapter 21
RESET
(MULTI DISPLAY)
02h CBh 0: No mean
8: Reset
Multi Display
Category
Momentary
DISPL AY P ROTE CTIO N
POWER SAVE Refer to Chapter 20
HEAT
STATUS
FAN1/2/3 02h 7Ah
/7Bh
Select target FAN. (7Ah)
0: No mean
1: FAN#1
2: FAN#2
3: FAN#3
Read status of target
FAN.(7Bh)
0: OFF
1: ON
2: ERROR
Read Only
BACKLIGHT Refer to Chapter 11 (Self-diagnosis status read)
TEMPERATURE
SENSOR1/2/3
02h 79h Return value is 2’s
complement.
(0.5°C
step)
Offset affects to
a selected
sensor.
Select sensor
(Page02h
OPcode78h)
1 : SENSOR #1
2 : SENSOR #2
3 : SENSOR #3
FAN CONTROL
COOLING FAN 02h 7Dh 0: No mean
1: AUTO
2: ON
FAN SPEED 10h 3Fh 0: No mean
1: HIGH
2: LOW
