(36/36)
Item OP
code
page
OP code Parameter Remarks
MAX VOL 10h D8h 0 (whisper)
|
100(64h) (laud)
INPUT 10h D9h 0: No mean
1: UNLOCK
2: LOCK
UNLOCK SELECT
10h DAh 0: No mean
1: VGA
2: RGB/HV
3: DVI
4: HDMI (Set only)
5: VIDEO
6: VIDEO2
7: S-VIDEO
12(0Ch): Y/Pb/Pr
13(0Dh): OPTION
14(0Eh): Y/Pb/Pr2
(SCART)
15(0Fh): DPORT
16(10h): DPORT2
17(11h): HDMI
128(80h): DPORT3
10h DBh
10h DCh
TILE MATRIX H MONITOR 02h D0h 0: No mean
1
|
10(0Ah)
Number
of H-division
V MONITOR 02h D1h 0: No mean
1
|
10(0Ah)
Number
of V-division
POSITION 02h D2h 0: No mean
1
|
100(64h)
TILE COMP 02h D5h 0: No mean
1: NO
2: YES
ENABLE 02h D3h 0: No mean
1: NO
2: YES
FRAME COMP 11h 01h 0: No mean
1: NONE
2: AUTO
3: MANUAL
Available on
X464UN, X554UN,
X464UNV, X554UNS
AUTO 11h 02h 0: No mean
50(32h): 0.5F
100(64h): 1.0F
150(96h): 1.5F
200(C8h): 2.0F
Available on
X464UN, X554UN,
X464UNV, X554UNS
This command is
used when FRAME
COMP is set as
“AUTO”.
MANUAL 11h 03h 0: No mean
25(19h): 0.25F
50(32h): 0.50F
75(4Bh): 0.75F
100(64h): 1.00F
125(7Dh): 1.25F
150(96h): 1.50F
175(Afh): 1.75F
200(C8h): 2.00F
Available on
X464UN, X554UN,
X464UNV, X554UNS
This command is
used when FRAME
COMP is set as
“MANUAL”.
