6.3. Operation Code (OP code) Table
Item OP
code
page
OP code Parameter Remarks
PICTU RE
BACKLIGHT 00h 10h 0: dark
|
100(64h): bright
CONTRAST 00h 12h 0: low
|
100(64h): high
SHARPNESS 00h 8Ch 0: dull
|
24(18h): sharp
BRIGHTNESS 00h 92h 0: dark
|
100(64h): bright
HUE 00h 90h 0: purplish
|
100(64h): greenish
COLOR 02h 1Fh 0: pale
|
100(64h): deep
COLOR TEMPERATURE 00h 54h 0:2600K
|
74(4Ah):10000K
100K/step
COLOR TEMPERATURE
(CUSTOM)
00h 14h 9: 10000K
11(0Bh): CUSTOM
R GAIN 00h 16h 0: Dark
|
255(FFh): Bright
B GAIN 00h 18h 0: Dark
|
255(FFh): Bright
G GAIN 00h 1Ah 0: Dark
|
255(FFh): Bright
COLOR CONTROL 00h RED:
9Bh
YELLOW:
9Ch
GREEN:
9Dh
CYAN:
9Eh
BLUE:
9Fh
MAGENTA:
A0h
0:
|
100(64h):(center)
|
200(C8h):
GAMMA CORRECTION 02h 68h 0: No mean
1: NATIVE
4: 2.2
8: 2.4
7: S GAMMA
5: DICOM SIM.
6: PROGRAMABLE1
13(0Bh): PROGRAMABLE2
14(0Ch): PROGRAMABLE3
MOVIE
SETTINGS
ADAPTIVE CONTRAST
02h 8Dh 0: No mean
1: Off
2: LOW
4: High
NOISE REDUCTION 02h 26h 0: Off
|
7: High
Page02 OPcode20h
also works as
same.
