(31/31)
Item OP
code
page
OP code Parameter Remarks
INPUT RESOLUTION 02h DAh Input Resolution select
0:No mean
1:Item 1(always Auto)
2:Item 2
3:Item 3
4:Item 4
5:Item 5
Ex)
Item 1= AUTO
Item 2= -- /
1024x768 /
1400x1050 /
800x600 /
1280x960
Item 3= -- /
1280x768 /
1680x1050 /
1024x576 /
1600x900 /
Item 4= -- /
1360x768 /
-- /
-- /
--
Item 5= -- /
1366x768
-- /
-- /
--
ASPECT 02h 70h 0: No mean
1: NORMAL
2: FULL
3: WIDE
4: ZOOM
6: DYNAMIC
7: 1:1
Wide:
Dynamic
A/V mode only
Zoom Control ZOOM 11h 2Ch 0-89(59h): No mean
90(5Ah): 90%
91(5Bh): 91%
|
100(64h): 100%
|
300(12Ch): 300%
The following
commands can also
be used.
OP code page 02h
OP code 6Fh
Parameter
0: No mean
1: 100%
2: 101%
|
201(C9h): 300%
H ZOOM 11h 2Dh 0-89(59h): No mean
90(5Ah): 90%
91(5Bh): 91%
|
100(64h): 100%
|
300(12Ch): 300%
The following
commands can also
be used.
OP code page 02h
OP code 6Ch
Parameter
0: No mean
1: 100%
2: 101%
|
201(C9h): 300%
