Example:

56h 47h 41h -> “VGA”

Result: Input Name is “VGA”.

Note: No null termination character is sent.

ETX (03h): End of Message

Check code

BCC: Block Check Code

Refer to the section 4.3 “Check code” for a BCC calculation.

Delimiter

CR (0Dh): End of packet
