31
4. Using Menus
When not displaying menus, the following screen is normally displayed.
When in standby
When the projector is in a standby state (the projector power switch is on), the following is displayed.
When power is turned on
When the power is turned on, the following is displayed.
← Displays the hours of lamp bulb use.
← Displays the lamp output (%).
← Displays the selected title.
← Displays the selected port.
When the power is turned off
The amount of time remaining for cooling is displayed as shown below, when the power to the projector head is turned off.
When a button is pressed while the key lock function is on
If a button on the control panel is pressed while the key lock function is on, the following is displayed and the button will not
function.
