ENGLISH
ENGLISH
24
Telescope Vacuum Pipe
The height-adjustable vacuum pipe enables
individual alignment to your height. Unlock the
coupling by pressing the key in the direction of the
arrow. Slide the vacuum pipe to the desired length.
To lock the device, release the key until you hear
it lock in place.
Using the Appliance
1. Unwind the length of cable you require.
CAUTION:
• Pull out the cable up to the maximum length indicated
with the yellow mark.
• Never pull the cable out up to the red mark as the
cable winding can be damaged.
NOTE:
If the red mark is visible, pull in the cable with the help of
the cable winding button back to the yellow mark.
2. Insert the mains plug into a correctly installed 230 V, 50 Hz
power socket. Turn the vacuum cleaner on by pressing the
on/off switch down with your foot.
3. Set the “carpet/hard fl oor” switch, depending on the fl oor
covering.
4. Set the vacuum power with the vacuum power regulator
(Min to Max).
5. Vacuum at a steady speed. There is no need to exert pres-
sure.
NOTE:
Pay attention to the range that can be covered with the cable
length!
Vacuum power regulator
Low vacuum power: For curtains and delicate fabrics.
Medium vacuum power: For long-pile velour carpets and textile
fl ooring.
High vacuum power: For sturdy rugs and fl oors.
Air Slide
Open the air slide on the hose handle in order to
regulate the airfl ow or to clear any particles sticking
to the nozzle.
Switching off and Winding up the Mains Lead
1. Turn the vacuum cleaner off by the on/off switch and remove
the plug from the socket.
2. Keep the plug in your hand.
3. Press the cable winding button and guide the cable. Hold
the cable to avoid wrapping.
Nozzle Attachment
Crevice and
jointed nozzle: For vacuuming upholstery, curtains and in
corners and crevices etc.
NOTE: „2-in-1“ nozzle:
When this is folded together it can be
used as a groove nozzle. If you would like
to use the brush nozzle, pull the brush
section in the direction of the arrow until it
locks in place.
Floor nozzle: To clean carpets or smooth surfaces.
Smooth fl oors: Press down the lever with
the brush symbol with your
foot. The brush is now vis-
ible.
Carpets: Press the lever In the oppo-
site direction. The brushes
are now retracted.
Parquet brush: The fl oor nozzle is fi tted with rollers for
improved manoeuvrability. For large areas
such as parquet, laminate or tiles etc.
Releasing
the nozzles: Pull these off while turning slightly.
Maintenance
Dust bag replacement display (6)
Hold the hose up into air. If the dust bag change display lights
up, the bag is full. Please change it.
Changing the dust bag
• Pull the plug out of the socket.
• Open the lid of the dust bag compartment by the handle
(11).
• Remove the bag by pulling the retainer carefully upwards so
that you have easier access to the bag. Then remove the
dust bag by pulling it upwards.
• Insert a new bag. Please ensure that the bag is located
correctly in the guide mechanism. Then reinsert the retainer.
Close the cover so that it snaps into place.
Filter
Your appliance has two fi lters.
Motor protection fi lter (inlet fi lter):
The inlet fi lter is located in the dust bag compartment. The
fi lter is located vertically in the rear section of the dust housing.
Remove the fi lter by pulling upwards.
Cleaning the Filter Element
Clean the engine protection fi lter after 10 dust bag changes. If
necessary, the fi lter can also be washed in warm water without
any additives. Place it back into place only once it is completely
dry!
05-BS 1275.indd 2405-BS 1275.indd 24 18.12.2008 14:09:06 Uhr18.12.2008 14:09:06 Uhr
