GRAPHITE 59G019 [20/192] Preparation for operation

The tool is designed for dry operation only. Use the power tool according to its purpose only.

Inappropriate use.

Ɣ Do not process materials that contain asbestos. Asbestos is a carcinogen.

Ɣ Do not process materials that produce ammable or explosive dust. During operation power tool

produces sparks that can ignite produced fumes.

Ɣ Do not grind with wheels designed for cutting. Cutting wheels work with front edge surface and

grinding with side surface of the wheel can cause damage, and in consequence personal injuries of the

operator.

DESCRIPTION OF DRAWING PAGES

Below enumeration refers to the device elements depicted on the drawing pages of this manual.

1. Cap of the spindle collet sleeve

2. Spindle

3. Guard

4. Spindle lock button

5. Carbon brush cover

6. Switch

7. Display

8. Buttons for control of rotation speed

9. Hanger

10. Flexible casing

11. Flexible shaft handle

12. Sleeve for exible shaft cord locking

13. Cap of the collet sleeve of the exible shaft

14. Auxiliary handle

* Dierences may appear between the product and drawing.

MEANING OF SYMBOLS

CAUTION

WARNING

ASSEMBLY/SETTINGS

INFORMATION

EQUIPMENT AND ACCESSORIES

1. Flexible shaft - 1 pce

2. Special at spanner - 1 pce

3. Additional guard - 1 pce

4. Auxiliary handle (attached to the tool) - 1 pce

5. Various accessories - 190 pcs

6. Plastic case - 1 pce

PREPARATION FOR OPERATION

INSTALLATION AND DEINSTALLATION OF AUXILIARY HANDLE

You can use minigrinder with or without auxiliary handle (14), according to your needs. Therefore, use

proper guard (3) with high or low ange.

Depending on the work ahead it is recommended to use auxiliary handle and hold the minigrinder

with both hands.

Disconnect the power tool from power supply.
