PREPARATION FOR OPERATION

INSTALLATION OF ADDITIONAL HANDLE

Due to personal safety issues it is recommended to always use the additional handle (5). Possibility

to rotate the additional handle before it is clamped on the drill body allows choosing the position

most comfortable for specic working conditions.

Disconnect the power tool from power supply.

Loosen the wheel lock that locks collar of the locking handle ( ● 5) by turning it counter-clockwise.

Slide the handle collar over cylindrical part of the drill body. ●

Turn for the most comfortable position. ●

Turn the wheel lock clockwise tightly to clamp the handle. ●

DEPTH GAUGE INSTALLATION

Depth gauge (6) serves to limit the depth of drill penetration of material

Loosen the wheel lock, which blocks collar of the additional handle ( ● 5).

Slide depth gauge rod ( ● 6) into the hole in the additional handle collar.

Set desired drill depth. ●

Fix by tightening the wheel lock. ●

INSTALLATION OF WORKING TOOLS

Disconnect the power tool from power supply.

Insert key into one of the holes on the side wall of the drill chuck ( ● 1).

Open jaws to desired dimension. ●

Insert cylindrical drill shank into the chuck, push it to the limit. ●

Tighten jaws on drill shank with the key (insert it into three holes on the chuck side wall). ●

Remember to always remove the key from the chuck after you nish drill installation or removal.

When a new drill is installed, observe against excessive drill wobble after start-up. This may indicate

improper xing in the chuck or deviated drill. If you observe wobbling, check xing of the drill and its

technical condition. Check drill chuck on a regular basis, before each use of the drill.

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

The mains voltage must match the voltage on the rating plate of the drill.

Switching on – press the switch button (4) and hold in this position.

Switching o – release pressure on the switch (4).

Locking the switch (continuous operation)

Switching on:

Press the switch button ( ● 4) and hold in this position.

Press the switch lock button ( ● 3) (g. A).

Release pressure on the switch ( ● 4).

Switching o:

Press and release the switch ( ● 4).

Range of rotational speed of the spindle is controlled with pressure on the switch button.
