ENGLISH
7
E
Turning Power On/Off
n
Operations after rst power-on
When you turn on the power for the rst time, a screen for
setting the date and time appears.
DATE/TIME
1 920x1080
The date/time setting must be set by Application.
[SET] : Display "Date & time" on Application
<APPLICATION>
01/01/2017 SUN 00:00
SET CANCEL
V: 60 Hz H: 67.5 kHz
1. Select “SET”, and set the time zone and date/time.
2. Select “Launcher:SHARP Open Architecture Platform”
in “Home”.
3.
Press the CONTENT MENU button on the remote control unit.
This is the base screen (CONTENT MENU screen) when
the input mode is APPLICATION.
For information on APPLICATION mode, see the Software Guide.
• Be sure to set the date and time.
TIPS
• The clock is maintained by the internal battery.
• If you already set the time but the date/time setting screen
appears when the power is turned on, the internal battery
may be exhausted. After replacing the internal battery, set
the date and time as explained in step 1 in the above.
•
Please contact an authorized SHARP servicing dealer or
service center for assistance with internal battery replacement.
• Estimated service life of the internal battery: About 5 years
(depending on monitor operation)
• The initial battery was inserted at the factory when the
monitor was shipped, so it may run out of power before its
expected operation life.
Caution
• Turn on the monitor rst before turning on the computer or
playback device.
• When switching the main power switch or the POWER
button off and back on, always wait for at least 5 seconds.
A short interval may result in a malfunction.
Turning on the main power
Main power switch
Caution
• The main power must be turned on/off with the main power
switch. Do not connect/disconnect the power cord or turn
the breaker on/off while the main power switch is on.
•
For a complete electrical disconnection, pull out the main plug.
Turning power on/off
Press the POWER button to turn the power ON/OFF.
You can also turn the power ON/OFF by pressing the
MONITOR ON button/MONITOR OFF button on the remote
control unit.
POWER button
Power LED
Status Status of the monitor
Green lit Power on
Orange lit Power off (Standby mode)
Green ashing Input signal waiting mode
• Setting the SCHEDULE ashes the power LED alternately
in red and orange in standby mode.
• A SCHEDULE is set by factory default in this monitor that
restarts the Android system at 3:00.
n
How to pull out the power LED/remote
control sensor
Pull out Store
Lever
Power LED / Remote control sensor
