35987-001_v01
the drive, and then, turn left to the position in which you will
hear “clicking” of the blocking. It means that the grinder has
been assembled correctly.
USAGE AND REGULATION OF THE GRINDER
Before the rst use, wash (see “CLEANING”) and dry
a disassembled grinder, and then grind around 50 grams of
product (f. e. corns) - set-up the grinding option of the device
with the medium comminute. The grinded product is not t to
use cause it` s polluted and its necessary throw it away.
Maximal time of uninterrupted work is around
15 minutes. This condition is connected with
maximal work time of machine, for which it
should be done the 45 minutes of pause after
15 minutes of operation.
The devices cannot operate without loading.
Each time before staring the device, ll it up
with product.
2
Fill the pan (8) with grain.
3
Set the body handle (3) to coarse grinding.
4
Turn on the mincer motor.
5
The ground product will pour out through the opening.
6
Depending on the desired grinding level or the type of
grain, adjust the burr regulator (2) with the body handle in
order to obtain the product with the adequate granulation
level. By turning it clockwise you will obtain a ner ground
product, by turning it counter-clockwise – coarser ground
product.
The nest (minimum) grinding level is achieved by setting
the handle to line 1, and the coarsest (maximum) grinding
level by setting it to the STOP line. See the graphic on the
body (3) and burr regulator (2).
By attempting to twist or turn the handle
beyond the STOP line during the operation you
can damage the device.
It` s recommended to set the quern regulator
during the grinder work time between the line
1 and STOP line.
It`s FORBIDDEN to use the REVERSE function
in the machine when the grinder is installed.
Remember about the accurate washing
the grinder before grinding of the different
products. It will permit to avoid the mutual
penetration of odors.
For the soft corns as oat or linseed it`s
necessary to select the coast�grained set up.
Do not look into the grinding chamber during
operation, as the beans which pop out
sometimes, can hurt you (i.e. your eye).
M
CLEANING AND MAINTENANCE
The grinder does not requires the cleaning after each
operation (if it`s grinded one kind of product), cause the
worm prevents falling the seeds residues into grinder. Dry
the steel quern (4, 5) using a soft cloth after cleaning to
prevent corrosion. In case of long-term storage, conserve
the quern by greasing them (you can use edible oil). Do
not immerse the quern into boiling water. The part of plastic
(don`t containing the graphic) can be washed in the dish-
washer (max. of 60°C).
Citrus juicer
The citrus juicer is an additional appliance, which enables to
squeeze juice from citrus fruits together with the pulp.
Construction of the appliance:
1
Clutch
2
Bowl
3
Screen
4
Squeezer
USING THE APPLIANCE
1
Open the lid of the compartment on the back of the
housing, which enables to operate the appliance in a vertical
position. Place the appliance on a hard, even surface.
2
Slide the coupling onto the drive.
3
Fix the bowl to the motor and turn left until you hear
a click. It means that the bowl has been properly installed.
4
Attach the screen and the squeezer to the protruding
part of the bowl.
Prepare the fruits by cutting them into halves.
●
Plug in the appliance.
●
5
Switch on the appliance using the „I” switch (1a) and
place the fruit on the squeezer with the pulp facing the
squeezer.
6
Push to start the squeezing process.
In case the sieve is blocked with the pulp of
extracted fruit, it is necessary to switch off the
appliance, disassemble the sieve and empty it,
as the excess of the pulp can cause leakage to
the motor chamber of the appliance.
The citrus juicer spins during operation. Pay
special attention to your ngers while pushing
the fruits on the squeezer.
After operation
Switch off and unplug the appliance.
●
1
Remove the pusher and take out the tray from the mincer
body, the shredder body or the juicer body (in case of the
citrus juicer separately remove the squeezer and screen).
2
Press the lock button, turn the mincing unit, the shredder
body (or the citrus juicer bowl) to the right and remove it.
L
N
G
