Hyundai Robex 250LC-7 [170/182] Starting circuit

4-6

2. STARTING CIRCUIT

OPERATING FLOW

Battery(+) terminal Battery relay〔CR-1〕 Fusible link 〔CN-60〕 Fuse box 〔No.1〕

I/conn 〔CN-8(12)〕 Start switch 〔CS-2(1)〕

When start key switch is in ON position

Start switch ON 〔CS-2(2)〕 I/conn 〔CN-8(11)〕 Battery relay 〔CR-1〕

Battery relay operating (All power is supplied with the electric component)

Start switch ON 〔CS-2(3)〕 I/conn 〔CN-8(10)〕 Power relay 〔CR-35(86) → (87)〕

Fuse box 〔No.12〕 l/conn 〔CN-2(5)〕 Fuel cut-off 〔CN-79 (1)〕

When start key switch is in START position

Start switch START 〔CS-2(5)〕 I/conn 〔CN-8(9)〕 Safety relay 〔CR-5(86) → (30)〕

l/conn 〔CN-3(2)〕 Start relay 〔CR-23〕

l/conn 〔CN-2(4)〕 Fuel cut off 〔CN-79(2)〕

CHECK POINT

(1)

(2)

Engine Start switch Check point

Voltage

OPERATING START

① - GND(Battery)

② - GND(Start key)

③ - GND(Battery relay M4)

④ - GND(Starter B

)

⑤ - GND(Starter M)

⑥ - GND(Start relay)

⑦ - GND(Battery relay M8)

20~25

※GND : Ground
