Hyundai Robex 250LC-7 [174/182] Head and work light circuit

4-10

4. HEAD AND WORK LIGHT CIRCUIT

OPERATING FLOW

Fuse box (No.14) I/conn 〔CN-7(7)〕 Switch panel 〔CN-116(9)〕

Fuse box (No.15) I/conn 〔CN-7(8)〕 Switch panel 〔CN-116(10,11)〕

Head light switch ON

Head light switch ON 〔CN-116(1)〕 l/conn 〔CN-7(1)]

Head light ON 〔CL-4(2)〕

l/conn 〔CN-10(2)〕 Cassette radio illumination ON 〔CN-27(7)〕

l/conn 〔CN-11(8)〕 AC & Heater controller illumination ON

l/conn 〔CN-6(8)〕 Cigarlight 〔CL-2〕

Work light switch ON

Work light switch ON 〔CN-116(2,3)〕 l/conn 〔CN-7(2)〕 l/conn 〔CN-12(1)〕

Work light ON 〔CL-5(2), CL-6(2)〕

CHECK POINT

※ GND : Ground

(1)

(2)

Engine Start switch Check point

Voltage

STOP ON

ONSTOP

① - GND(Fuse box)

② - GND(Switch power input)

③ - GND(Switch power output)

④ - GND(Head light)

⑤ - GND(Fuse box)

⑥ - GND(Switch power input)

⑦- GND(Switch power output)

⑧ - GND(Work light)

20~25
