15
CONTROL AND REGULATION DIAGRAMS
pCO1: CAREL regulation
pCOe: Additional CAREL regulation
board(Economiser option)
PC1/2: Converter
CONV 1/2: Circuits 1 and 2 electronic regulator
converters
EEV1/2: Electronic regulator
EP1/2: Circuits 1 and 2 low pressure sensors
Q1/2/3/4: C1/2/3/4 compressors additional
magneto-thermal circuit breaker
Q5: Blower fan additional magneto-thermal
circuit breaker
Q10/11/12/13: Heating elements additional
magnetic circuit breaker
OF1/OF2: MO1/MO2 motors internal protection
FM: Heating manual reset safety thermostat
FA: Heating automatic reset safety
thermostat
KA1: Three-phase network control relay (phase
sequence and cut-out) contact
HP1/2: Circuits 1 and 2 automatic reset high-
pressure pressostats
LP1/2: Circuits 1 and 2 automatic reset low-
pressure pressostats
OCT1/2: Circuits 1 and 2 condenser temperature
sensor
RAT: Intake air temperature sensor
CST1/2: Circuits 1 and 2 compressor air intake
temperature sensor
OAT: Outdoor air temperature sensor (option)
SAT: Blown air temperature sensor (option)
RAH: Intake air hygrometry sensor (option)
IAQ: Intake air quality sensor (option)
OAH: Outdoor air hygrometry sensor (option)
SD: Smoke detector (option)
ECM: Economiser dampers motor (option)
HWV: Hot water battery valve (option)
CONV 3: Hot water battery valve converter
(option)
CONV 4: Variators ACS5/8 order 0-10V converter
HWC: Anti-freezing, hot water battery warning
DFA1: Clogged filter warning (ΔP>250Pa)
DFA2: Clogged bag filter warning (ΔP>500Pa)
AF: Air pressostat (ΔP<50Pa)
ON/OFF: ON/OFF switch (not supplied)
SWS: Winter/Summer switch
KM1/2/3/4: C1/2/3/4 compressors power contactor
KM5/6/7/8/9: Fan power contactors
KM10/11/12/13: H eating elements power
contactors
EV1/2: Circuits 1 and 2 cycle inversion valve
KA6/7: Circuits 1 and 2 heating demand auxiliary
relays
M8: Intake fan motor
M9: Extractor fan motor
AS5: Motor M5 "Soft start"
AS8: Motor M8 "Soft start"
Q10/11/12/13: Heating elements magnetic circuit
breakers
KM10/11/12/13: Heating elements power contactors
CH.1: Small capacity heating option
CH.2: Large capacity hearting option
BURNER: Option burner gas
