16
PRESSOSTATS SETTING
Factory high pressure adjustment 42bars (609.17PSI )
Clogged filter
ΔP warning (upstream/downstream filters) > 250 Pa
Airflow detector ΔP warning (upstream/downstream blower)< 50 Pa
RANGE AND SETTINGS OF THEMAL PROTECTION / NOMINAL INTENSITY OF THE
CONTACTORS (CLASSE AC3)
Model
100 120 140 160
PE GE PE GE PE GE PE GE
Q1 Range 20-25A 20-25A 20-25A 24-32A
Adjustment 21A 22A 23A 32A
Q2 Range 20-25A 20-25A 20-25A 24-32A
Adjustment 21A 22A 23A 32A
Q3 Range 20-25A 20-25A 20-25A 24-32A
Adjustment 21A 22A 23A 32A
Q4 Range 20-25A 20-25A 20-25A 24-32A
Adjustment 21A 22A 23A 32A
Q5 Range 13-18A 13-18A 13-18A 13-18A
Adjustment 15A 15A 15A 15A
Q6 Range 2.5-4A 2.5-4A 2.5-4A 2.5-4A
Adjustment 3.5A 3.5A 3.5A 3.5A
Q7 Range 2.5-4A 2.5-4A 2.5-4A 2.5-4A
Adjustment 3.5A 3.5A 3.5A 3.5A
Q8 Range 13-18A 13-18A 13-18A 13-18A
Adjustment 15A 15A 15A 15A
Q9 Range 4-6.3A 4-6.3A 4-6.3A 4-6.3A
Adjustment 6A 6A 6A 6A
Contactor AC3
K1 25A 25A 25A 32A
K2 25A 25A 25A 32A
K3 25A 25A 25A 32A
K4 25A 25A 25A 32A
K5 18A 18A 18A 18A
K6 6A 6A 6A 6A
K7 6A 6A 6A 6A
K8 18A 18A 18A 18A
K9 9A 9A 9A 9A
COMPRESSORS CRANKCASE HEATER
Models 100 120 140 160
Power W 90 65 90 65
