Performance data in cooling mode - HFC 407C
LCWT
(°C) Pf Pabs Pf Pabs Pf Pabs Pf Pabs Pf Pabs Pf Pabs Pf Pabs
5
21.6 6.1 21.0 6.8 20.8 7.1 20.4 7.5 18.7 8.2 17.8 8.7 16.8 9.2
6
22.3 6.1 21.7 6.8 21.4 7.1 21.0 7.5 19.3 8.2 18.4 8.7 17.3 9.3
7
23.0 6.1 22.4 6.9 22.1 7.2
21.5 7.6
20.0 8.3 19.0 8.8 17.9 9.3
8
23.8 6.2 23.2 6.9 22.9 7.2 22.4 7.6 20.7 8.4 19.6 8.8 18.5 9.4
9
24.5 6.2 23.9 7.0 23.6 7.2 23.1 7.7 21.3 8.4 20.3 9.0 19.2 9.5
10
25.2 6.4 24.6 7.0 24.3 7.3 23.8 7.7 22.0 8.5 20.9 9.0 19.8 9.5
5
26.5 7.5 25.8 8.2 25.5 8.6 24.9 9.0 22.9 9.9 21.8 9.9 20.6 10.4
6
27.4 7.6 26.7 8.3 26.3 8.6 25.7 9.1 23.8 10.0 22.5 10.0 21.3 10.5
7
28.3 7.7 27.6 8.4 27.2 8.7
26.0 9.2
24.6 10.1 23.2 10.1 22.0 10.6
8
29.2 7.7 28.4 8.5 28.0 8.8 27.5 9.3 25.3 10.1 24.0 10.1 22.8 10.7
9
30.1 7.8 29.3 8.5 29.0 8.9 28.4 9.4 26.1 10.2 24.9 10.2 23.5 10.8
10
31.0 7.9 30.2 8.6 29.9 8.9 29.3 9.4 27.1 10.3 25.7 10.3 24.3 10.9
5
31.0 8.6 29.6 9.4 29.0 9.8 28.1 10.4 26.3 11.4 25.1 12.1 24.0 12.7
6
31.9 8.7 30.5 9.5 29.9 9.9 29.0 10.5 27.1 11.5 26.0 12.2 24.8 12.8
7
32.9 8.8 31.4 9.6 30.8 10.0
29.9 10.6
27.9 11.7 26.8 12.3 25.7 12.9
8
33.8 8.8 32.4 9.7 31.7 10.1 30.8 10.7 28.8 11.8 27.7 12.4 26.5 13.0
9
34.8 8.9 33.3 9.8 32.7 10.2 31.7 10.8 29.7 11.8 28.5 12.4 27.2 13.2
10
35.9 9.0 34.3 9.9 33.6 10.3 32.6 10.9 30.6 12.0 29.3 12.5 28.1 13.3
5
34.9 9.5 33.6 10.4 33.0 10.7 32.1 11.2 29.4 12.4 27.9 13.3 26.2 14.1
6
36.0 9.6 34.6 10.5 34.1 10.8 33.2 11.3 30.5 12.6 28.8 13.4 27.2 14.2
7
37.0 9.8 35.7 10.6 35.1 11.0
34.2 11.4
31.5 12.7 29.8 13.5 28.2 14.4
8
38.1 9.9 36.8 10.7 36.2 11.1 35.3 11.5 32.6 12.8 30.9 13.6 29.2 14.4
9
39.3 10.0 38.0 10.9 37.4 11.2 36.4 11.6 33.7 12.9 32.0 13.7 30.3 14.5
10
40.4 10.1 39.1 11.0 38.6 11.3 37.7 11.7 34.9 12.9 33.2 13.7 31.5 14.5
5
39.6 12.7 38.4 14.0 38.0 14.5 37.3 15.3 34.5 16.7 32.8 17.6 31.1 18.7
6
40.7 12.8 39.7 14.1 39.1 14.6 38.3 15.4 35.5 16.9 33.9 17.8 32.1 18.8
7
41.9 12.8 40.8 14.2 40.3 14.7
39.5 15.5
36.6 17.0 34.8 17.9 33.0 18.9
8
43.1 13.0 41.9 14.3 41.4 14.8 40.6 15.6 37.7 17.1 35.8 18.0 34.0 19.1
9
44.3 13.1 43.2 14.4 42.6 14.9 41.8 15.7 38.8 17.2 36.9 18.2 35.1 19.2
10
45.5 13.2 44.4 14.5 43.8 15.0 42.9 15.9 39.9 17.3 38.0 18.4 36.1 19.3
5
48.3 15.4 46.8 16.8 46.3 17.4 45.3 18.3 41.6 20.0 39.5 21.0 37.4 22.1
6
49.7 15.5 48.3 17.0 47.6 17.6 46.5 18.5 42.9 20.2 40.7 21.2 38.5 22.3
7
51.1 15.7 49.6 17.2 49.0 17.8
47.9 18.7
44.1 20.4 41.9 21.4 39.6 22.6
8
52.5 15.9 51.0 17.3 50.3 17.9 49.2 18.9 45.5 20.7 43.1 21.7 40.8 22.8
9
54.0 16.0 52.4 17.5 51.8 18.1 50.6 19.1 46.7 20.9 44.4 21.9 42.1 23.0
10
55.4 16.2 53.8 17.7 53.2 18.3 52.1 19.3 48.1 21.0 45.6 22.2 43.3 23.3
5
56.4 18.8 54.7 20.5 54.0 21.2 52.8 22.3 48.8 24.4 46.5 25.7 44.0 26.9
6
58.0 18.9 56.3 20.7 55.6 21.4 54.4 22.6 50.2 24.6 47.7 25.9 45.3 27.2
7
59.6 19.1 57.9 21.0 57.1 21.7
55.9 22.8
51.7 24.9 49.0 26.1 46.5 27.5
8
61.3 19.4 59.5 21.1 58.7 21.9 57.4 23.0 53.0 25.2 50.3 26.5 47.7 27.8
9
62.9 19.5 61.1 21.3 60.3 22.1 59.0 23.3 54.5 25.4 51.8 26.7 49.0 28.1
10
64.6 19.7 62.7 21.5 61.9 22.3 60.6 23.5 55.9 25.7 53.1 27.0 47.8 28.4
5
69.9 22.3 66.8 24.3 65.6 25.1 63.7 26.6 59.6 28.9 57.0 30.4 54.6 31.9
6
72.0 22.3 68.9 24.5 67.6 25.4 65.5 26.8 61.3 29.2 58.8 30.7 56.2 32.2
7
74.0 22.5 70.8 24.7 69.5 25.6
67.0 27.0
63.1 29.4 60.5 30.9 57.9 32.6
8
76.2 22.7 72.9 24.9 71.5 25.8 69.4 27.2 65.0 29.7 62.2 31.3 59.5 32.9
9
78.3 23.0 74.9 25.1 73.6 26.0 71.3 27.4 66.8 30.0 64.1 31.5 61.2 33.1
10
80.4 23.2 77.0 25.4 75.5 26.3 73.4 27.8 68.7 30.3 65.9 31.8 63.1 33.4
5
75.5 24.3 73.4 26.6 72.5 27.6 70.9 29.1 65.6 31.6 62.4 33.3 59.3 35.0
6
77.7 24.4 75.4 26.8 74.5 27.8 73.0 29.4 67.5 32.0 64.2 33.7 61.0 35.4
7
79.9 24.7 77.6 27.1 76.6 28.0
75.1 29.6
69.3 32.2 66.0 33.9 62.6 35.7
8
82.0 24.9 79.7 27.3 78.7 28.3 77.1 29.8 71.3 32.6 67.8 34.3 64.3 36.1
9
84.3 25.2 81.9 27.6 80.8 28.5 79.2 30.1 73.2 32.8 69.6 34.5 66.1 36.3
10
86.5 25.4 84.1 27.8 83.0 28.9 81.3 30.4 75.1 33.2 71.5 34.9 67.8 36.7
80
40
50
60
70
20
25
30
35
AQH
sizes
Outdoor air temperature (°C)
25 30 32 35 40 43 46
All the cooling capacity and power consumption values are expressed in kW.
The values indicated in bold are based on Eurovent conditions (chilled water inlet / outlet temperatures of 12 / 7 °C and an outdoor air
temperature of + 35 °C).
The power consumption values stated in the table include compressors and fans in operation.
LCWT: Leaving Chilled Water Temperature
Pf : Cooling capacity
Pabs : Power consumption
