Dimensions - RWR 170 to 360
Sizes 1-2 3 4
170 to 360 DN 100 (4") 1" 3/8 7/8"
LEGEND
1 Evaporator water in
2 Evaporator water out
3 Discharge line connection
4 Liquid line connection
