Page 40
Technical data
SLS HE-BLN/HE-LN/HE-ELN 4202 4602 4802 4804 5204 5604 6004 6404 6804 7204 7804 8404
Nominal voltage
V/ph/Hz
400-3-50
Number of circuits 2 2 2 4 4 4 4 44444
Number of steps 6 6 6 9 9 9 9 99999
Capacity steps % 25 25 25 25 25 25 25 25 25 25 25 25
Refrigerant
Type R134a
Charge (1) kg
103+103 105+105 108+108
73+73/ 75+75/ 78+78/ 82+82/ 87+87/ 90+90/ 93+93/ 96+96/ 99+99/
73+73 75+75 78+78 82+82 87+87 90+90 93+93 96+96 99+99
Compressors
Type Screw
Number 2 2 2 4 4 4 4 44444
Start-up type S/D (Star-delta)
Evaporator
Type Shell & Tube
Number 1 1 1 2 2 2 2 22222
Minimum water content l 462 423 423 184 222 222 295 462 462 462 423 423
Condenser
Type Coil type (Al/Cu)
Hydraulic connections
Type Victaulic
Inlet diameter inch 8" 8" 8" 6" 6" 6" 8" 8" 8" 8" 8" 8"
Outlet diameter inch 8" 8" 8" 6" 6" 6" 8" 8" 8" 8" 8" 8"
Weights
Shipping HE-BLN kg
10790 11240 11270 12680 13160 13510 14940 16050 16100 16140 16480 16610
Shipping HE-LN/HE-ELN kg
10910 11360 11390 12920 13400 13750 15180 16290 16340 16380 16720 16850
Operating HE-BLN kg
11250 11700 11730 13050 13600 13960 15530 16980 17020 17060 17330 17460
Operating HE-LN/HE-ELN
kg
11370 11820 11850 13290 13840 14200 15770 17220 17260 17300 17570 17700
Dimensions
Length mm 8000 8000 8000 12000 12000 12000 12000 12000 12000 12000 12000 12000
Width mm 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200
Height mm 2550 2550 2550 2550 2550 2550 2550 2550 2550 2550 2550 2550
(1) Indicative value. Always refer to the value specified on the unit’s label.
