Page 44
Technical data
Electrical data - Standard Unit
SLS STD-LN / STD-ELN 1402 1602 1802 1902 2002 2202 2502 2702
Nominal voltage
V(%)-ph-Hz
400 ±10% / 3 / 50
Nominal power input kW 79 115 134 151 168 184 194 204
Max power input kW 161 181 200 215 230 250 261 272
Nominal current A 141 195 220 252 284 310 328 346
Max. current (FLA) A 257 297 338 358 378 448 464 480
Max. start-up current (LRA) A 386 460 550 650 664 483 510 521
External fuses (A) 315 315 400 400 400 500 500 500
Wire cross area (1) mm
2
240 240 2x120 2x120 2x120 2x185 2x185 2x185
SLS STD-LN / STD-ELN 3002 3202 3402 3602 4202 4602 4802 5004
Nominal voltage
V(%)-ph-Hz
400 ±10% / 3 / 50
Nominal power input kW 209 237 251 265 279 333 350 194+194
Max power input kW 277 321 342 362 380 444 462 261+261
Nominal current A 356 405 429 453 476 551 578 328+328
Max. current (FLA) A 490 548 583 618 648 702 752 464+464
Max. start-up current (LRA) A 625 584 663 687 788 899 934 841
External fuses (A) 630 630 800 800 800 800 800 500+500
Wire cross area (1) mm
2
2x240 2x240 2x300 2x300 2x300 2x300 2x300
2x185+2x185
SLS STD-LN / STD-ELN 5404 5704 6004 6404 6804 7204 8404
Nominal voltage
V(%)-ph-Hz
400 ±10% / 3 / 50
Nominal power input kW 204+204 204+226 226+226 237+237 251+251 265+265 279+279
Max power input kW 272+272 272+301 301+301 321+321 342+342 362+362 380+380
Nominal current A 346+346 346+379 379+379 405+405 429+429 453+453 476+476
Max. current (FLA) A 480+480 480+539 539+539 548+548 583+583 618+618 648+648
Max. start-up current (LRA) A 863 958 1011 975 1079 1128 1249
External fuses (A) 500+500 500+630 630+630 630+630 800+800 800+800 800+800
Wire cross area (1) mm
2
2x185+2x185 2x185+2x240 2x240+2x240 2x240+2x240 2x300+2x300 2x300+2x300 2x300+2x300
(1) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working temperature
in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
SLS2-en.qxp 29-06-2007 15:38 Pagina 44
