Page 48
Technical data
Compressors SLS HE 1402 1602 1802 1902 2002 2402 2602 2802
Number n° 22222222
Nominal power input kW 2x37 2x55 2x63 63+79 2x79 2x87 87+97 2x97
Max power input kW 2x78 2x88 2x96 96+110 2x110 2x120 120+131 2x131
Nominal current A 2x66 2x93 2x103 103+133 2x133 2x146 146+164 2x164
Max. current (FLA) A 2x124 2x144 2x162 162+180 2x180 2x215 215+231 2x231
Max. start-up current (LRA) A 2x290 2x350 2x423 423+520 2x520 2x314 314+341 2x341
Oil treater power input W 2x200 2x200 2x200 200+300 2x300 2x300 2x300 2x300
Compressors SLS HE 3002 3202 3402 3602 4202 4602 4802 4804
Number n° 22222224
Nominal power input kW 97+114 2x111 111+125 2x125 2x132 149+166 2x166
2x87+2x87
Max power input kW 131+155 2x153 153+174 2x174 2x183 204+222 2x222
2x120+2x120
Nominal current A 164+187 2x189 189+213 2x213 2x224 246+273 2x273
2x146+2x146
Max. current (FLA) A 231+280 2x260 260+295 2x295 2x310 310+360 2x360
2x215+2x215
Max. start-up current (LRA) A 341+436 2x374 374+453 2x453 2x543 586+650 2x650
2x314+2x314
Oil treater power input W 2x300 2x300 2x300 2x300 2x300 2x300 2x300 4x300
Compressors SLS HE 5204 5604 6004 6404 6804 7204 7804 8404
Number n° 44444444
Nominal power input kW
2x(87+97) 2x97+2x97 2x(97+114)
2x111+2x111 2x(111+125) 2x125+2x125 2x125+2x132 2x132+2x132
Max power input kW
2x(120+131)
2x131+2x131 2x(131+155) 2x153+2x153
2x(153+174) 2
x174+2x174 2x174+2x183 2x183+2x183
Nominal current A
2x(146+164)
2x164+2x164 2x(164+187) 2x189+2x189 2x(189+213) 2x213+2x213 2x213+2x224 2x224+2x224
Max. current (FLA) A
2x(215+231) 2x231+2x231 2x(231+280)
2x260+2x260 2x(260+295) 2x295+2x295 2x295+2x310 2x310+2x310
Max. start-up current (LRA) A
2x(314+341)
2x341+2x341 2x(341+436) 2x374+2x374 2x(374+453) 2x453+2x453 2x453+2x543 2x543+2x543
Oil treater power input W 4x300 4x300 4x300 4x300 4x300 4x300 4x300 4x300
Electrical data - Compressors
